Name: PIC16LF18324-I/JQ
Brand: Microchip Technology
SKU: PIC16LF18324-I/JQ
Price: 1.29000 USD
Availability: InStock

new-10%

PIC16LF18324-I/JQ

Manufacturer part number:PIC16LF18324-I/JQ

Manufacturer:Microchip Technology

Description:7KB 4K x 14 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 16F Series PIC16LF18324 32MHz 3V 16-UQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC16LF18324-I/JQ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Mounting Type	Surface Mount
Package / Case	16-UQFN Exposed Pad
Surface Mount	YES
Supplier Device Package	16-UQFN (4x4)
Mounting Style	SMD/SMT
Interfaces	I2C/SPI/USART
Instruction Set Architecture	RISC
Clock Freq	32(MHz)
DAC Resolution	5
Operating Temperature Classification	Industrial
Package Type	UQFN EP
Number of Timers - General Purpose	7
Operating Temp Range	-40C to 85C
# I/Os (Max)	12
Power Dissipation (Max)	800(mW)
Interface Type	I2C/SPI/USART
Total Internal Ram Size	512B(kB)
Device Core Size	8(b)
Operating Supply Voltage (Max)	3.6(V)
Operating Supply Voltage (Typ)	2.5/3.3(V)
Rad Hardened	No
Operating Supply Voltage (Min)	1.8(V)
Programmable	Yes
Mounting	Surface Mount
Data Converters	A/D 11x10b, D/A 1x5b
Package	Tube
Base Product Number	PIC16LF18324
Mfr	Microchip Technology
Product Status	Active
Number of I/Os	12 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	PIC
RoHS	Details
Schedule B	8542310000/8542310000/8542310000/8542310000/8542310000
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	PIC® XLP™ 16F
Published	2016
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	16
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	NO LEAD
Supply Voltage	3V
Terminal Pitch	0.65mm
Frequency	32MHz
Base Part Number	PIC16LF18324
Pin Count	16
JESD-30 Code	S-PQCC-N16
Qualification Status	Not Qualified
Operating Temperature (Max)	85C
Operating Temperature (Min)	-40C
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	2/3.3V
Supply Voltage-Min (Vsup)	1.8V
Interface	I2C, LIN, SPI, UART, USART
Memory Size	7kB
Oscillator Type	Internal
Number of I/O	12
Speed	32MHz
RAM Size	512 x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	7KB 4K x 14
Connectivity	I2C, LINbus, SPI, UART/USART
Supply Current-Max	3.2mA
Bit Size	8
Data Converter	A/D 11x10b; D/A 1x5b
Has ADC	YES
DMA Channels	NO
Data Bus Width	8 bit
PWM Channels	YES
DAC Channels	YES
Product Type	8-bit Microcontrollers - MCU
ROM (words)	8192
Core Architecture	PIC
EEPROM Size	256 x 8
Boundary Scan	NO
Low Power Mode	YES
Format	FIXED-POINT
Integrated Cache	NO
RAM (words)	1024
Number of ADC Channels	11 Channel
Number of Serial I/Os	1
Number of Timers	7
Number of External Interrupts	1
On Chip Data RAM Width	8
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Length	4mm
Height Seated (Max)	0.55mm
Width	4mm
RoHS Status	ROHS3 Compliant

PIC16LF18324-I/JQ Product Details

PIC16LF18324-I/JQ Overview

In a 16-UQFN Exposed Pad package, the MCU is available. 12 I/Os are available. The Microcontroller has a mounting type of Surface Mount, which indicates that it is mounted conveniently. The 8-Bit core is the core of the MCU. There is a FLASH type of memory for its program. There is a temperature range of -40°C~85°C TA that is operated by this Microcontroller. PIC® XLP™ 16F series components make up this electrical component. 7KB 4K x 14 is the size of its program memory. A PIC Core processor is used to power the device. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 16 is the number of terminations on the IC chip that are present. This part works in a 8-bit manner. There is a 3V volt supply output on the chip. DMA channels number NO. 7kB is the memory size of the part. The base part number PIC16LF18324 can be used to find alternatives. The efficiency of this device can be improved when operating at a frequency of 32MHz. The device works in YES PWM channels. There are 16 pins on it. It has built-in FLASH memory. There is an integrated PIC core architecture in it. A total of 11 Channel channels of ADC are available on this device. There are 1 serial I/Os incorporated into the chip part. This part contains 1 external interrupts which provide a high level of flexibility. It is possible to have 7 bits in a IC chip.
