Name: PIC16LF1455T-I/ML
Brand: Microchip Technology
SKU: PIC16LF1455T-I/ML
Availability: InStock

new-10%

PIC16LF1455T-I/ML

Manufacturer part number:PIC16LF1455T-I/ML

Manufacturer:Microchip Technology

Description:14KB 8K x 14 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 16F Series PIC16LF1455 16 Pin 48MHz 16-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC16LF1455T-I/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Mounting Type	Surface Mount
Package / Case	16-VQFN Exposed Pad
Surface Mount	YES
Number of Pins	16
Supplier Device Package	16-QFN (4x4)
Interfaces	I2C/SPI/USART/USB
Package	Tape & Reel (TR)
Base Product Number	PIC16LF1455
Mfr	Microchip Technology
Data Converters	A/D 5x10b; D/A 1x5b
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® XLP™ 16F
Published	2012
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	16
Terminal Finish	Matte Tin (Sn)
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Terminal Pitch	0.65mm
Frequency	48MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC16LF1455
Operating Supply Voltage	3.6V
Interface	I2C, LIN, SPI, UART, USART, USB
Oscillator Type	Internal
Number of I/O	8
Speed	48MHz
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	14KB 8K x 14
Connectivity	I2C, LINbus, SPI, UART/USART, USB
Bit Size	8
Data Converter	A/D 5x10b; D/A 1x5b
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	YES
EEPROM Size	-
On Chip Program ROM Width	14
Device Core	PIC
Length	4mm
Height Seated (Max)	1mm
RoHS Status	ROHS3 Compliant

PIC16LF1455T-I/ML Product Details

PIC16LF1455T-I/ML Overview

There is a 16-VQFN Exposed Pad package available. The board has 8 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 8-Bit core is used in order to power the IC chip. The type of memory it uses for its program is FLASH. -40°C~85°C TA is the temperature range at which this Microcontroller operates. PIC® XLP™ 16F-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 14KB 8K x 14. Powered by a PIC Core processor. Microcontroller's a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. IC Chip terminations are 16. As a result, this Microcontroller comes with a 8-bit size. A total of NO DMA channels are available. There are a number of alternatives to the base part number PIC16LF1455 that you can find. Performing well when operated at frequency 48MHz can be achieved. Using YES PWM channels, the device works. On the chip, there are 16 pins that can be accessed.
