PIC16F767-E/SP Overview
Packaged in a 28-DIP (0.300, 7.62mm) format, this MCU is available in a compact size. There are 25 I/Os on the Microcontroller. It is important to note that the Microcontroller has a Through Hole mounting type. 8-Bit core is the basis for this Microcontroller. This program has a type of memory called FLASH for this MCU's program memory. Temperatures in this range are operated by this Microcontroller. The PIC® 16F series includes this electrical component. There is 14KB 8K x 14 bytes of program memory in MCU, which corresponds to the size of the program. With a PIC Core processor, MCU is equipped with the latest technology available. This is a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. During the manufacturing process, 28 terminations were applied to the IC chip. 8-bits are used in Microcontroller. The MCU chip's supply output is 5V volts. Currently, MCU chip has NO DMA channels. 14kB memory size belongs to the Chip part. Alternatives can be found by looking at the base part number PIC16F767. In the case of 20MHz frequency operation, it can perform efficiently. There are YES PWM channels on the device. The chip has 28 pins. The clock has 3 timers/counters to keep track of the time. 28 pins are counted on this board. This device is embedded with a PIC processor family, which is a powerful and efficient CPU.
PIC16F767-E/SP Features
28-DIP (0.300, 7.62mm) package
Mounting type of Through Hole
PIC16F767-E/SP Applications
There are a lot of Microchip Technology
PIC16F767-E/SP Microcontroller applications.
- Equipment control
- Instrument control
- Toys
- Robots
- Radio
- Television
- Heater/Fan
- Calculator
- Kindle
- Christmas lights
