Name: PIC16C74A-10/P
Brand: Microchip Technology
SKU: PIC16C74A-10/P
Price: 12.98000 USD
Availability: InStock

new

PIC16C74A-10/P

Manufacturer part number:PIC16C74A-10/P

Manufacturer:Microchip Technology

Description:7KB 4K x 14 OTP PIC 8-Bit Microcontroller PIC® 16C Series PIC16C74A 40 Pin 10MHz 5V 40-DIP (0.600, 15.24mm)

Case Package:SOT-23

Datasheet:PIC16C74A-10/P Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mounting Type	Through Hole
Package / Case	40-DIP (0.600, 15.24mm)
Surface Mount	NO
Number of Pins	40
Supplier Device Package	40-PDIP
Mounting Style	Through Hole
Interfaces	I2C/SPI/USART
Number of I/Os	33 I/O
Maximum Operating Temperature	+ 70 C
Minimum Operating Temperature	0 C
Interface Type	I2C, SPI, USART
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	PIC
RoHS	Details
Package	Tube
Base Product Number	PIC16C74
Mfr	Microchip Technology
Data Converters	A/D 8x8b
Product Status	Active
Operating Temperature	0°C~70°C TA
Packaging	Tube
Series	PIC® 16C
Published	1997
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	40
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Power Dissipation	1W
Terminal Position	DUAL
Supply Voltage	5V
Frequency	10MHz
Base Part Number	PIC16C74A
Pin Count	40
Operating Supply Voltage	5V
Power Supplies	5V
Interface	I2C, SPI, UART, USART
Memory Size	7kB
Oscillator Type	External
Number of I/O	33
Speed	10MHz
RAM Size	192 x 8
Voltage - Supply (Vcc/Vdd)	4V~6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	OTP
Core Size	8-Bit
Program Memory Size	7KB 4K x 14
Connectivity	I2C, SPI, UART/USART
Bit Size	8
Data Converter	A/D 8x8b
Watchdog Timer	Yes
Access Time	10 μs
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
Number of Timers/Counters	3
Product Type	8-bit Microcontrollers - MCU
EEPROM Size	-
On Chip Program ROM Width	14
CPU Family	PIC
Number of ADC Channels	8
Number of PWM Channels	2
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Width	13.84 mm
Height	3.81 mm
Length	52.26 mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC16C74A-10/P Product Details

PIC16C74A-10/P Overview

It comes in a 40-DIP (0.600, 15.24mm) package. It has a number of 33I/Os. The Mounting Type of the device is Through Hole. It is based on the 8-Bit. The It?ˉs Program Memory Type is OTP. The device runs in 0??C~70??C TA Operating Temperature. It runs in PIC? 16C Series.

PIC16C74A-10/P Features

PIC? 16C series
Base part number of PIC16C74A
40 Terminals
Based on the 8-Bit
Comes with 40 Pins

PIC16C74A-10/P Applications

There are a lot of Microchip Technology PIC16C74A-10/P Microcontroller applications. PIC16C74A-10/P MCU is usually applied for Measurement and control field, Consumer electronics products, Network communication, mobile communication, Office automation equipment and computer peripherals, Industrial control Instrumentation and process control, Agriculture, transportation, Navigation control, Network application, Metering & measurement, Day to day life, Safety, Medical instruments and Automobile industry.
