Name: MIC94355-4YMT-T5
Brand: Microchip Technology
SKU: MIC94355-4YMT-T5
Availability: InStock

new-10%

MIC94355-4YMT-T5

Manufacturer part number:MIC94355-4YMT-T5

Manufacturer:Microchip Technology

Description:Enable Fixed 0.5 mm MIC94355 PMIC Ripple Blocker™ Series 8 6-UFDFN Exposed Pad

Case Package:SOT-23

Datasheet:MIC94355-4YMT-T5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	6-UFDFN Exposed Pad
Surface Mount	YES
Supplier Device Package	6-TDFN (1.6x1.6)
Number of Terminals	6
Supplier Package	TDFN EP
Input Voltage Range	1.8 to 3.6 V
Maximum Input Voltage	3.6 V
Junction to Ambient	92 °C/W
Mounting	Surface Mount
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MIC94355
Mfr	Microchip Technology
Product Status	Obsolete
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	Ripple Blocker™
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code	8542.39.00.01
Technology	CMOS
Terminal Position	DUAL
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.5 mm
Reach Compliance Code	compliant
Base Part Number	MIC94355
Pin Count	8
JESD-30 Code	S-PDSO-N6
Function	LDO
Number of Outputs	1
Voltage - Input (Max)	3.6V
Output Voltage	1.2V
Output Type	Fixed
Polarity	Positive
Output Configuration	Positive
Output Current	0.5 A
Current - Output	500mA
Control Features	Enable
Voltage - Output (Min/Fixed)	1.2V
Number of Regulators	1
Protection Features	Over Current, Over Temperature
Current - Quiescent (Iq)	250μA
Voltage Dropout (Max)	0.2V @ 500mA
PSRR	85dB ~ 50dB (100Hz ~ 5MHz)
Seated Height-Max	0.6 mm
Output Voltage1-Max	1.236 V
Output Voltage1-Min	1.164 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.2 V
Screening Level	Extended Industrial
Operating Temperature TJ-Max	125 °C
Line Regulation	1 %
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	1.2 V
Load Regulation	10 mV
Width	1.6 mm
Length	1.6 mm
RoHS Status	ROHS3 Compliant

MIC94355-4YMT-T5 Product Details

MIC94355-4YMT-T5 Overview

Tape & Reel (TR) cases are used for delivery. The Liner regulator IC is packaged in 6-UFDFN Exposed Pad case. Fixed is the output type of the Voltage Regulator IC. As part of this electrical component, 1 regulators are implemented. Variations are made to the Surface Mount operating temperature range by the Voltage Regulator IC. Default settings are set to -40°C~125°C degrees. There is a Positive configured as the output function for this IC regulator. There is a current output of 500mA from this regulator IC. On this chip, there are a total of 8 pins in total. There are 1 outputs total on this voltage regulator IC in order to ensure that prompt and sufficient performance is achieved. For your information, the basic part number for this regulator IC is MIC94355. There is one type of regulator for this device, which is FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR. This IC regulator is a part of the Ripple Blocker™ Series of devices.
