Name: MIC5321-JGYMT-TR
Brand: Microchip Technology
SKU: MIC5321-JGYMT-TR
Price: 1.11000 USD
Availability: InStock

new-10%

MIC5321-JGYMT-TR

Manufacturer part number:MIC5321-JGYMT-TR

Manufacturer:Microchip Technology

Description:Enable Fixed 0.5 mm MIC5321 PMIC -- Series 6 6-UFDFN Exposed Pad, 6-TMLF®

Case Package:SOT-23

Datasheet:MIC5321-JGYMT-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	6-UFDFN Exposed Pad, 6-TMLF®
Surface Mount	YES
Number of Pins	6
Supplier Device Package	6-TMLF® (1.6x1.6)
Number of Terminals	6
Mounting Style	SMD/SMT
Supplier Package	uDFN
Input Voltage Range	2.3, 5.5 V
Maximum Input Voltage	5.5 V
Junction to Ambient	100 °C/W
Mounting	Surface Mount
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package	Tape & Reel (TR)
Base Product Number	MIC5321
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Published	2008
Series	--
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Technology	CMOS
Terminal Position	DUAL
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.5 mm
Reach Compliance Code	compliant
Base Part Number	MIC5321
Pin Count	6
JESD-30 Code	S-PDSO-N6
Function	LDO
Number of Outputs	2
Qualification Status	Not Qualified
Voltage - Input (Max)	5.5V
Output Voltage	1.8V
Output Type	Fixed
Polarity	Positive
Output Configuration	Positive
Output Current	0.15 A
Current - Output	150mA, 150mA
Control Features	Enable
Voltage - Output (Min/Fixed)	1.8V 2.5V
Number of Regulators	2
Protection Features	Over Current, Over Temperature
Current - Quiescent (Iq)	190μA
Voltage Dropout (Max)	0.1V @ 150mA 0.1V @ 150mA
PSRR	75dB ~ 45dB (1kHz ~ 20kHz)
Seated Height-Max	0.6 mm
Dropout Voltage	35mV
Product Type	LDO Voltage Regulators
Output Voltage1-Max	2.575 V
Output Voltage1-Min	2.425 V
Regulator Type	FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Output Current1-Max	0.15 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.1 V
Min Current Limit	300mA
Screening Level	Extended Industrial
Operating Temperature TJ-Max	125 °C
Line Regulation	0.3 %/V
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	2.5 V
Load Regulation	2 %
Output Voltage2-Max	1.854 V
Output Voltage2-Min	1.746 V
Output Current2-Max	0.15 A
Dropout Voltage2-Max	0.1 V
Product Category	LDO Voltage Regulators
Width	1.6 mm
Length	1.6 mm
RoHS Status	ROHS3 Compliant

MIC5321-JGYMT-TR Product Details

MIC5321-JGYMT-TR Overview

A Tape & Reel (TR) case is used to deliver this IC regulator. This voltage regulator IC comes in a 6-UFDFN Exposed Pad, 6-TMLF® case. Output type Fixed. This component features 2 Voltage regulators. As a result of the Linear Voltage Regulator's design, the operating temperature of Surface Mount can be adjusted within a specified range. There is a temperature range of -40°C~125°C degrees during operation of the IC regulator. There is a configuration in this voltage regulator IC that specifies that its output function is Positive. In terms of its current output, it is able to supply 150mA, 150mA. A total of 6 pins can be found on the board. In order to deliver prompt, sufficient and reliable performance, this regulator IC has 2 outputs in total. A dropout voltage of 10 volts can be obtained from this voltage regulator IC. There are 6 pins on the chip. As an FYI, this IC voltage regulator has the basic part number MIC5321. An example of such a component would be this PMIC - Power Management ICs component. This device is regulated with the FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR type of regulator. This model is a part of the -- Series and is of high quality. If the temperature is below 125°C, it is recommended that you utilize this feature. It is recommended that the chip be operated at a temperature no lower than -40°C operating temperature.
