Name: MIC5281YMME
Brand: Microchip Technology
SKU: MIC5281YMME
Price: 1.93000 USD
Availability: InStock

new-10%

MIC5281YMME

Manufacturer part number:MIC5281YMME

Manufacturer:Microchip Technology

Description:-- Adjustable 0.65 mm MIC5281 PMIC -- Series 8 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad

Case Package:SOT-23

Datasheet:MIC5281YMME Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Surface Mount	YES
Number of Pins	8
Supplier Device Package	8-MSOP-EP
Number of Terminals	8
Mounting Style	SMD/SMT
Supplier Package	MSOP EP
Input Voltage Range	6 to 120 V
Maximum Input Voltage	120 V
Junction to Ambient	64 °C/W
Mounting	Surface Mount
Dimensions	3 x 3 x 0.86mm
Package Type	MSOP
Maximum Operating Temperature	+125 °C
Minimum Operating Temperature	-40 °C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package	Tube
Base Product Number	MIC5281
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Operating Temperature	-40°C~125°C
Packaging	Tube
Published	2011
Series	--
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Terminal Pitch	0.65 mm
Reach Compliance Code	compliant
Base Part Number	MIC5281
Pin Count	8
JESD-30 Code	S-PDSO-G8
Function	Standard
Number of Outputs	1
Voltage - Input (Max)	120V
Output Voltage	5.5V
Output Type	Adjustable
Max Output Current	25mA
Polarity	Positive
Output Configuration	Positive
Output Current	0.025 A
Current - Output	25mA
Quiescent Current	11μA
Control Features	--
Accuracy	3 %
Max Output Voltage	5.5V
Voltage - Output (Min/Fixed)	1.27V
Number of Regulators	1
Min Input Voltage	6V
Protection Features	Over Current, Over Temperature
Current - Quiescent (Iq)	11μA
Voltage Dropout (Max)	3V @ 25mA
Max Input Voltage	120V
PSRR	90dB (20kHz ~ 2MHz)
Reference Voltage	1.308V
Seated Height-Max	1.04 mm
Dropout Voltage	2V
Product Type	Linear Voltage Regulators
Min Output Voltage	1.27V
Power Supply Rejection Ratio (PSRR)	90dB
Output Voltage1-Max	5.5 V
Output Voltage1-Min	1.27 V
Regulator Type	Linear Voltage
Output Current1-Max	0.025 A
Voltage - Output (Max)	5.5V
Dropout Voltage1-Max	3 V
Min Current Limit	30mA
Screening Level	Extended Industrial
Operating Temperature TJ-Max	125 °C
Line Regulation	0.5 %
Operating Temperature TJ-Min	-40 °C
Load Regulation	1 %
Product Category	Linear Voltage Regulators
Height	860μm
Length	3mm
Width	3mm
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant

MIC5281YMME Product Details

MIC5281YMME Overview

A Tube case is used to deliver this IC regulator. This voltage regulator IC comes in a 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad case. Output type Adjustable. This component features 1 Voltage regulators. As a result of the Linear Voltage Regulator's design, the operating temperature of Surface Mount can be adjusted within a specified range. There is a temperature range of -40°C~125°C degrees during operation of the IC regulator. There is a configuration in this voltage regulator IC that specifies that its output function is Positive. In terms of its current output, it is able to supply 25mA. A total of 8 pins can be found on the board. In order to deliver prompt, sufficient and reliable performance, this regulator IC has 1 outputs in total. A dropout voltage of 10 volts can be obtained from this voltage regulator IC. There are 8 pins on the chip. As an FYI, this IC voltage regulator has the basic part number MIC5281. An example of such a component would be this PMIC - Power Management ICs component. This device is regulated with the Linear Voltage type of regulator. Taking into account the operation requirements, the maximum output current of the IC voltage regulator reaches 25mA. It operates in the 11μA Quiescent Current state. This model is a part of the -- Series and is of high quality. If the temperature is below 125°C, it is recommended that you utilize this feature. It is recommended that the chip be operated at a temperature no lower than -40°C operating temperature.
