Name: MIC5255-3.3BM5-TR
Brand: Microchip Technology
SKU: MIC5255-3.3BM5-TR
Availability: InStock

new-10%

MIC5255-3.3BM5-TR

Manufacturer part number:MIC5255-3.3BM5-TR

Manufacturer:Microchip Technology

Description:Enable Fixed 0.95 mm MIC5255 PMIC - Series 5 SC-74A, SOT-753

Case Package:SOT-23

Datasheet:MIC5255-3.3BM5-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	SC-74A, SOT-753
Surface Mount	YES
Supplier Device Package	SOT-23-5
Number of Terminals	5
Package	Tape & Reel (TR)
Base Product Number	MIC5255
Mfr	Microchip Technology
Product Status	Discontinued at Digi-Key
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	-
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Technology	CMOS
Terminal Position	DUAL
Terminal Form	GULL WING
Number of Functions	1
Terminal Pitch	0.95 mm
Reach Compliance Code	unknown
Base Part Number	MIC5255
Pin Count	5
JESD-30 Code	R-PDSO-G5
Qualification Status	Not Qualified
Voltage - Input (Max)	6V
Output Type	Fixed
Output Configuration	Positive
Current - Output	150mA
Control Features	Enable
Voltage - Output (Min/Fixed)	3.3V
Number of Regulators	1
Protection Features	Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)	150μA
Voltage Dropout (Max)	0.25V @ 150mA
PSRR	60dB ~ 50dB (10Hz ~ 10kHz)
Seated Height-Max	1.45 mm
Output Voltage1-Max	3.366 V
Output Voltage1-Min	3.234 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	0.15 A
Voltage - Output (Max)	-
Dropout Voltage1-Max	0.25 V
Operating Temperature TJ-Max	125 °C
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	3.3 V
Width	1.6 mm
Length	2.9 mm
RoHS Status	Non-RoHS Compliant

MIC5255-3.3BM5-TR Product Details

MIC5255-3.3BM5-TR Overview

The package contains a Tape & Reel (TR) case. In SC-74A, SOT-753 cases, it is packaged. Fixed is the IC Voltage Regulator's output type. A total of 1 regulators are implemented in this eletric component. Surface Mount operating temperature varies depending on the IC Voltage Regulator. The Regulator IC chip is set to operate at -40°C~125°C degrees. It has been configured that the output function of this IC regulator is Positive. There is an output of 150mA at the moment. 5 pins make up the sum of this IC voltage regulator. I just wanted to let you know that this IC voltage regulator has the part number MIC5255 as its basic part number. This device is controlled by a FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR type regulator. It belongs to the - Series of regulators.
