Name: MIC5200-3.3BS TR
Brand: Microchip Technology
SKU: MIC5200-3.3BS TR
Availability: InStock

new-10%

MIC5200-3.3BS TR

Manufacturer part number:MIC5200-3.3BS TR

Manufacturer:Microchip Technology

Description:-- Fixed 2.31 mm MIC5200 PMIC -- Series 3 TO-261-4, TO-261AA

Case Package:SOT-23

Datasheet:MIC5200-3.3BS TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	TO-261-4, TO-261AA
Surface Mount	YES
Supplier Device Package	SOT-223-3
Number of Terminals	4
Package	Tape & Reel (TR)
Base Product Number	MIC5200
Mfr	Microchip Technology
Product Status	Obsolete
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	--
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn85Pb15)
HTS Code	8542.39.00.01
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	240
Number of Functions	1
Terminal Pitch	2.31 mm
Reach Compliance Code	compliant
Base Part Number	MIC5200
Pin Count	3
JESD-30 Code	R-PDSO-G4
Current - Supply (Max)	1.5mA
Qualification Status	Not Qualified
Voltage - Input (Max)	26V
Output Type	Fixed
Output Configuration	Positive
Current - Output	100mA
Control Features	--
Voltage - Output (Min/Fixed)	3.3V
Number of Regulators	1
Protection Features	Over Current, Over Temperature
Current - Quiescent (Iq)	350μA
Voltage Dropout (Max)	0.35V @ 100mA
PSRR	--
Seated Height-Max	1.8 mm
Output Voltage1-Max	3.366 V
Output Voltage1-Min	3.234 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	0.1 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.35 V
Operating Temperature TJ-Max	125 °C
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	3.3 V
Width	3.505 mm
Length	6.5 mm
RoHS Status	Non-RoHS Compliant

MIC5200-3.3BS TR Product Details

MIC5200-3.3BS TR Overview

Tape & Reel (TR) cases are used for delivery. The Liner regulator IC is packaged in TO-261-4, TO-261AA case. Fixed is the output type of the Voltage Regulator IC. As part of this electrical component, 1 regulators are implemented. Variations are made to the Surface Mount operating temperature range by the Voltage Regulator IC. Default settings are set to -40°C~125°C degrees. There is a Positive configured as the output function for this IC regulator. There is a current output of 100mA from this regulator IC. There are a total of 3 pins on this board. For your information, the basic part number for this regulator IC is MIC5200. There is one type of regulator for this device, which is FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR. This IC regulator is a part of the -- Series of devices.
