Name: MIC49150WR-TR
Brand: Microchip Technology
SKU: MIC49150WR-TR
Price: 4.09000 USD
Availability: InStock

new-10%

MIC49150WR-TR

Manufacturer part number:MIC49150WR-TR

Manufacturer:Microchip Technology

Description:Enable Adjustable 1.7 mm MIC49150 PMIC -- Series 5 SPak-5 (5 leads + Tab)

Case Package:SOT-23

Datasheet:MIC49150WR-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	SPak-5 (5 leads + Tab)
Surface Mount	YES
Number of Pins	5
Supplier Device Package	S-PAK-5
Number of Terminals	5
Mounting Style	SMD/SMT
Supplier Package	S-PAK
Junction to Case	2 °C/W
Input Voltage Range	1.4 to 6.5 V
Maximum Input Voltage	6.5 V
Mounting	Surface Mount
Polarity Type	Positive
Regulator Output Type	Adjustable
Voltage Regulator Type	Linear
Dropout Voltage@Current (Max)	0.2@750mA/[email protected]
Operating Temperature Classification	Automotive
Package Type	SPAK
Dropout Voltage@Current (Typ)	0.13@750mA/[email protected]
Operating Temp Range	-40C to 125C
Rad Hardened	No
MSL	MSL 3 - 168 hours
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MIC49150
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	--
Tolerance	1 %
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
ECCN Code	EAR99
Type	LDO
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Terminal Position	SINGLE
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Terminal Pitch	1.7 mm
Reach Compliance Code	not_compliant
Base Part Number	MIC49150
Pin Count	5
JESD-30 Code	R-PSSO-G5
Function	LDO
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	6.5V
Output Voltage	5V
Output Type	Adjustable
Max Output Current	1.5A
Polarity	Positive
Output Configuration	Positive
Output Current	1.5 A
Current - Output	1.5A
Control Features	Enable
Input Voltage (Min)	1.4(V)
Voltage - Output (Min/Fixed)	0.9V
Topology	LDO
Number of Regulators	1
Min Input Voltage	1.4V
Protection Features	Over Current, Over Temperature
Voltage Dropout (Max)	0.5V @ 1.5A
Input Voltage (Max)	6.5 V
Max Input Voltage	6.5V
PSRR	--
Reference Voltage	900mV
Seated Height-Max	2.03 mm
Dropout Voltage	280mV
Product Type	LDO Voltage Regulators
Output Voltage1-Max	5 V
Output Voltage1-Min	0.9 V
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	1.5 A
Voltage - Output (Max)	5V
Dropout Voltage1-Max	0.5 V
Min Current Limit	1.6A
Screening Level	Extended Industrial
Operating Temperature TJ-Max	125 °C
Output Voltage Accuracy	1 %
Line Regulation	0.1 %/V
Operating Temperature TJ-Min	-40 °C
Load Regulation	1 %
Input Voltage	6.5(V)
Product Category	LDO Voltage Regulators
Output Voltage Range	900 mV to 5 V
Width	8 mm
Length	9.015 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

MIC49150WR-TR Product Details

MIC49150WR-TR Overview

An Tape & Reel (TR) case is included with the delivery. There is a SPak-5 (5 leads + Tab) case with the integrated voltage regulator. In terms of output type, Adjustable is what the Regulator IC produces. The electronic component implements 1 Voltage regulator ICs. IC Regulator is possible to alter the range of the operating temperature of Surface Mount in the device. In order for this IC voltage regulator to operate, the temperature has to be kept at -40°C~125°C degrees. In this case, the output function that is configured for this regulator IC is Positive. There is an 1.5Amp current output on this voltage regulator IC. It has a total of 5 pins on IC voltage regulator. In order to ensure prompt, adequate, and prompt performance, this regulator has 1 outputs in total. In terms of its dropout voltage, it is 10 volts. There are 5 pins on the chip. It is MIC49150 for this regulator, just for your information. In this instance, we are dealing with a typical PMIC - Power Management ICs-shaped component. It is worth mentioning that the regulator type for this regulator IC is ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR. In order to meet the operating requirements of the regulator, its maximal output current reaches 1.5A. This regulator IC is a part of the -- Series. Utilize the regulator IC when the temperature is below 125°C. It is recommended that the chip be operated at a temperature no lower than -40°C operating temperature. The tolerance on this voltage regulator IC is 1 %, a relatively low value.
