Name: MIC2954-03BZ-TR
Brand: Microchip Technology
SKU: MIC2954-03BZ-TR
Availability: InStock

new-10%

MIC2954-03BZ-TR

Manufacturer part number:MIC2954-03BZ-TR

Manufacturer:Microchip Technology

Description:-- Fixed 1.27 mm MIC2954 PMIC -- Series 3 TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)

Case Package:SOT-23

Datasheet:MIC2954-03BZ-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount	NO
Supplier Device Package	TO-92-3
Number of Terminals	3
Package	Tape & Reel (TR)
Base Product Number	MIC2954
Mfr	Microchip Technology
Product Status	Discontinued at Digi-Key
Package Shape	ROUND
Manufacturer	Microchip Technology Inc
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Published	2007
Series	--
JESD-609 Code	e0
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn80Pb20)
HTS Code	8542.39.00.01
Subcategory	Other Regulators
Packing Method	TAPE AND REEL
Technology	BIPOLAR
Terminal Position	BOTTOM
Terminal Form	THROUGH-HOLE
Peak Reflow Temperature (Cel)	240
Number of Functions	1
Terminal Pitch	1.27 mm
Reach Compliance Code	compliant
Base Part Number	MIC2954
Pin Count	3
JESD-30 Code	O-XBCY-T3
Current - Supply (Max)	12mA
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	30V
Output Type	Fixed
Output Configuration	Positive
Current - Output	250mA
Control Features	--
Voltage - Output (Min/Fixed)	5V
Number of Regulators	1
Protection Features	Load Dump, Over Current, Over Temperature, Reverse Polarity, UV POR
Current - Quiescent (Iq)	300μA
Voltage Dropout (Max)	0.6V @ 250mA
PSRR	--
Dropout Voltage1-Nom	0.375 V
Output Voltage1-Max	5.12 V
Output Voltage1-Min	4.88 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max	2.4%
Output Current1-Max	0.25 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.6 V
Operating Temperature TJ-Max	125 °C
Input Voltage Absolute-Max	60 V
Adjustability	FIXED
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	5 V
RoHS Status	Non-RoHS Compliant

MIC2954-03BZ-TR Product Details

MIC2954-03BZ-TR Overview

The package contains a Tape & Reel (TR) case. In TO-226-3, TO-92-3 (TO-226AA) (Formed Leads) cases, it is packaged. Fixed is the IC Voltage Regulator's output type. A total of 1 regulators are implemented in this eletric component. Through Hole operating temperature varies depending on the IC Voltage Regulator. The Regulator IC chip is set to operate at -40°C~125°C degrees. It has been configured that the output function of this IC regulator is Positive. There is an output of 250mA at the moment. 3 pins make up the sum of this IC voltage regulator. As a result of this IC voltage regulator's 1 outputs, it ensures prompt, adequate performance for all your applications. I just wanted to let you know that this IC voltage regulator has the part number MIC2954 as its basic part number. In terms of components, this is an example of a Other Regulators component. This device is controlled by a FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR type regulator. In this case, the IC voltage regulator will be packed in the following way. It belongs to the -- Series of regulators.
