Name: MCP1811AT-012/HCA
Brand: Microchip Technology
SKU: MCP1811AT-012/HCA
Availability: InStock

new-10%

MCP1811AT-012/HCA

Manufacturer part number:MCP1811AT-012/HCA

Manufacturer:Microchip Technology

Description:Enable Fixed 0.65mm PMIC - Series 4-UDFN Exposed Pad

Case Package:SOT-23

Datasheet:MCP1811AT-012/HCA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	4-UDFN Exposed Pad
Surface Mount	YES
Supplier Device Package	4-UDFN (1x1)
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MCP1811
Mfr	Microchip Technology
Product Status	Obsolete
Packaging	Tape & Reel (TR)
Operating Temperature	-40°C ~ 85°C (TJ)
Series	-
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	4
Terminal Finish	Matte Tin (Sn)
Packing Method	TR
Terminal Position	DUAL
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.65mm
Time@Peak Reflow Temperature-Max (s)	30
JESD-30 Code	S-PDSO-N4
Current - Supply (Max)	110 µA
Number of Outputs	1
Voltage - Input (Max)	5.5V
Output Type	Fixed
Output Configuration	Positive
Current - Output	150mA
Control Features	Enable
Output Voltage 1	1.2V
Input Voltage (Min)	1.8V
Voltage - Output (Min/Fixed)	1.2V
Number of Regulators	1
Protection Features	Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq)	500 nA
Voltage Dropout (Max)	0.6V @ 150mA
Input Voltage (Max)	5.5V
PSRR	50dB (1kHz)
Dropout Voltage1-Nom	0.4V
Output Voltage1-Max	1.248V
Output Voltage1-Min	1.152V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max	4%
Output Current1-Max	0.15A
Voltage - Output (Max)	-
Dropout Voltage1-Max	0.6V
Operating Temperature TJ-Max	85°C
Input Voltage Absolute-Max	6V
Adjustability	FIXED
Operating Temperature TJ-Min	-40°C
Length	1mm
Height Seated (Max)	0.6mm
Width	1mm
RoHS Status	ROHS3 Compliant

MCP1811AT-012/HCA Product Details

MCP1811AT-012/HCA Overview

Deliveries are in Tape & Reel (TR) cases. The package is in a 4-UDFN Exposed Pad case. Basically, the voltage regulator chip is made up of 4 terminations. In this case, Fixed represents the output type of the Voltage Regulated IC. This part implements 1 regulator ICs, which can be found in the following table. Regulator IC varies the range of Surface Mount operating temperatures. The Voltage Regulated IC operates at a temperature of -40°C ~ 85°C (TJ) degrees, which is its operating temperature. It is configured for output function Positive on this regulator. There is an output current of 150mA on this regulator. This IC regulator has a total of 1 outputs, which ensures a rapid, adequate performance when in use. A FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR regulator is the type of regulator that is used for this device. Packing the voltage regulator IC in this way is called TR packing. As part of the - Series, this IC voltage regulator belongs to that category.
