Name: DSPIC33EP64GP504T-E/ML
Brand: Microchip Technology
SKU: DSPIC33EP64GP504T-E/ML
Availability: InStock

new-10%

DSPIC33EP64GP504T-E/ML

Manufacturer part number:DSPIC33EP64GP504T-E/ML

Manufacturer:Microchip Technology

Description:64KB 22K x 24 FLASH dsPIC 16-Bit Microcontroller Automotive, AEC-Q100, dsPIC™ 33EP Series DSPIC33EP64GP504 44 Pin 60MHz 44-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33EP64GP504T-E/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	19 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-VQFN Exposed Pad
Surface Mount	YES
Number of Pins	44
Supplier Device Package	44-QFN (8x8)
Number of Terminals	44
Data Converters	A/D 9x10b/12b
Package	Tape & Reel (TR)
Base Product Number	DSPIC33EP64GP504
Mfr	Microchip Technology
Product Status	Obsolete
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	35
Operating Temperature	-40°C~125°C TA
Packaging	Tape & Reel (TR)
Series	Automotive, AEC-Q100, dsPIC™ 33EP
Published	2006
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	3A001.A.3
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.31.00.01
Subcategory	Digital Signal Processors
Technology	CMOS
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Terminal Pitch	0.65 mm
Reach Compliance Code	compliant
Frequency	60MHz
Base Part Number	DSPIC33EP64GP504
Pin Count	44
JESD-30 Code	S-PQCC-N44
Qualification Status	Not Qualified
Operating Supply Voltage	3.3V
Power Supplies	3.3 V
Temperature Grade	AUTOMOTIVE
Interface	CAN, I2C, IrDA, LIN, SPI, UART, USART
Max Supply Voltage	3.6V
Min Supply Voltage	2.95V
Memory Size	64kB
Oscillator Type	Internal
Number of I/O	35
Speed	60 MIPs
RAM Size	4K x 16
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	64KB 22K x 24
Connectivity	CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max	150 mA
Bit Size	16
Data Converter	A/D 9x10b/12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	5
ROM (words)	21845
Core Architecture	dsPIC
EEPROM Size	--
On Chip Program ROM Width	24
Max Frequency	60MHz
Number of Programmable I/O	35
Format	FLOATING POINT
RAM (words)	4096
RAM (bytes)	8192
ROM Programmability	FLASH
Width	8 mm
Length	8 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

DSPIC33EP64GP504T-E/ML Product Details

DSPIC33EP64GP504T-E/ML Overview

This Microcontroller comes in a 44-VQFN Exposed Pad package. This Microcontroller has 35 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 16-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~125°C TA Operating Temperature. Microcontroller runs in Automotive, AEC-Q100, dsPIC™ 33EP Series. The size of the program memory of Microcontroller is 64KB 22K x 24. MCU is powered by dsPIC Core Processor. The device belongs to MICROCONTROLLER uPs/uCs/Peripheral ICs Type. Microcontroller comes with 16 bit size. MCU chip has YES DMA channels. The part owns 64kB memory size. You can find alternatives through the base part number DSPIC33EP64GP504. MCU's frequency is 60MHz. The device works in YES PWM channels. The pin number of the component remains 44. It has 5 timers/counters. It counts 44 pins. This equipment features FLASH memory. It has a dsPIC core architecture integrated into it. It programs in 35 Programmable I/O.
