Name: DSPIC33EP512GM604T-I/ML
Brand: Microchip Technology
SKU: DSPIC33EP512GM604T-I/ML
Availability: InStock

new-10%

DSPIC33EP512GM604T-I/ML

Manufacturer part number:DSPIC33EP512GM604T-I/ML

Manufacturer:Microchip Technology

Description:512KB 170K x 24 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 33EP Series DSPIC33EP512GM604 3.3V 44-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33EP512GM604T-I/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	44-VQFN Exposed Pad
Surface Mount	YES
Supplier Device Package	44-QFN (8x8)
Number of Terminals	44
Data Converters	A/D 18x10b/12b
Qualification	AEC-Q100
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	dsPIC
RoHS	Details
Package	Tape & Reel (TR)
Base Product Number	DSPIC33EP512GM604
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	35
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	dsPIC™ 33EP
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	44
ECCN Code	3A001.A.3
Terminal Finish	Matte Tin (Sn)
Additional Feature	70 MIPS, ADC ALSO SUPPORTS 10-BIT RESOLUTION
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	0.65mm
Reach Compliance Code	compliant
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC33EP512GM604
JESD-30 Code	S-PQCC-N44
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	3.3V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	3V
Oscillator Type	Internal
Number of I/O	35
Speed	70 MIPs
RAM Size	48K x 8
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT
Clock Frequency	60MHz
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	512KB 170K x 24
Connectivity	CANbus, I2C, IrDA, LINbus, QEI, SPI, UART/USART
Supply Current-Max	60 mA
Bit Size	16
Data Converter	A/D 18x10b/12b
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Product Type	DSP - Digital Signal Processors & Controllers
ROM (words)	524288
EEPROM Size	--
On Chip Program ROM Width	8
Screening Level	TS 16949
Format	FLOATING-POINT
RAM (words)	24576
RAM (bytes)	49152
ROM Programmability	FLASH
Product	DSPs
Product Category	Digital Signal Processors & Controllers - DSP, DSC
Length	8mm
Height Seated (Max)	1mm
Width	8mm
RoHS Status	ROHS3 Compliant

DSPIC33EP512GM604T-I/ML Product Details

DSPIC33EP512GM604T-I/ML Overview
