Name: DSPIC33EP32MC202T-E/SS
Brand: Microchip Technology
SKU: DSPIC33EP32MC202T-E/SS
Availability: InStock

new-10%

DSPIC33EP32MC202T-E/SS

Manufacturer part number:DSPIC33EP32MC202T-E/SS

Manufacturer:Microchip Technology

Description:32KB 10.7K x 24 FLASH dsPIC 16-Bit Microcontroller Automotive, AEC-Q100, dsPIC™ 33EP Series DSPIC33EP32MC202 28 Pin 60MHz 3.3V 28-SSOP (0.209, 5.30mm Width)

Case Package:SOT-23

Datasheet:DSPIC33EP32MC202T-E/SS Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	Production (Last Updated: 2 years ago)
Factory Lead Time	28 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	28-SSOP (0.209, 5.30mm Width)
Surface Mount	YES
Number of Pins	28
Supplier Device Package	28-SSOP
Number of Terminals	28
Data Converters	A/D 6x10b/12b
Package	Tape & Reel (TR)
Base Product Number	DSPIC33EP32MC202
Mfr	Microchip Technology
Product Status	Obsolete
RoHS	Compliant
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Number of I/O Lines	21
Operating Temperature	-40°C~125°C TA
Packaging	Tape & Reel (TR)
Series	Automotive, AEC-Q100, dsPIC™ 33EP
Published	2006
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	125 °C
Min Operating Temperature	-40 °C
HTS Code	8542.31.00.01
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	0.65 mm
Reach Compliance Code	compliant
Frequency	60MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC33EP32MC202
Pin Count	28
JESD-30 Code	R-PDSO-G28
Qualification Status	Not Qualified
Operating Supply Voltage	3.3V
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	3.3 V
Temperature Grade	AUTOMOTIVE
Interface	I2C, IrDA, LIN, SPI, UART, USART
Max Supply Voltage	3.6 V
Min Supply Voltage	2.95 V
Memory Size	32kB
Oscillator Type	Internal
Number of I/O	21
Speed	60 MIPs
RAM Size	2K x 16
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	32KB 10.7K x 24
Connectivity	I2C, IrDA, LINbus, QEI, SPI, UART/USART
Supply Current-Max	150 mA
Bit Size	16
Data Converter	A/D 6x10b/12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	2 mm
Number of Timers/Counters	5
ROM (words)	10922
Core Architecture	dsPIC
EEPROM Size	--
On Chip Program ROM Width	24
Max Frequency	60 MHz
Number of Programmable I/O	21
Format	FLOATING-POINT
RAM (words)	2048
RAM (bytes)	4096
ROM Programmability	FLASH
Length	10.2mm
Height Seated (Max)	2mm
Width	5.3 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

DSPIC33EP32MC202T-E/SS Product Details

DSPIC33EP32MC202T-E/SS Overview

The package is in 28-SSOP (0.209, 5.30mm Width) format. The MCU has 21 I/O ports. There is a mounting type Surface Mount associated with this Microcontroller. This Microcontroller is based on the 16-Bit core. There is a memory type of FLASH in its program memory. The temperature range that this Microcontroller operates at is -40°C~125°C TA. The electrical component that you are looking at belongs to the Automotive, AEC-Q100, dsPIC™ 33EP series of components. Microcontroller has abundant program memory size of 32KB 10.7K x 24. The dsPIC Core Processor powers the device and is one of its key features. This Microcontroller belongs to the MICROCONTROLLER uPs/uCs/peripheral ICs type. During the manufacture of the IC chip, there is a number 28 of terminations. A 16-bit operation is performed by this part. There is an output of 3.3V volts from the Microcontroller chip. A total of YES DMA channels are available on MCU chip. This MCU is implemented with 32kB memory. DSPIC33EP32MC202 serves as a base part number to find alternatives. It exhibits good efficiency when it operates at a frequency of 60MHz and it is able to operate at a high frequency. It is possible for the device to work with the motor using the PWM channel YES. It is possible to access the 28 pins on the chip through the 28 pins. It is equipped with 5 timers and counters. It consists of 28 pins. There's an integrated FLASH memory in the equipment. There is a dsPIC core architecture integrated into it. Among the eight programmable I/O sections, there are many different ways in which it can be programmed.
