Name: DSPIC33EP256GP506T-I/MR
Brand: Microchip Technology
SKU: DSPIC33EP256GP506T-I/MR
Availability: InStock

new-10%

DSPIC33EP256GP506T-I/MR

Manufacturer part number:DSPIC33EP256GP506T-I/MR

Manufacturer:Microchip Technology

Description:256KB 85.5K x 24 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 33EP Series DSPIC33EP256GP506 64 Pin 70MHz 3.3V 64-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33EP256GP506T-I/MR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	64-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	64
Supplier Device Package	64-QFN (9x9)
Number of Terminals	64
Data Converters	A/D 16x10b/12b
Package	Tape & Reel (TR)
Base Product Number	DSPIC33EP256GP506
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	53
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	dsPIC™ 33EP
Published	2012
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	64
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn) - annealed
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	0.5 mm
Reach Compliance Code	compliant
Frequency	70MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC33EP256GP506
Pin Count	64
JESD-30 Code	S-PQCC-N64
Qualification Status	Not Qualified
Operating Supply Voltage	3.3V
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	3.3 V
Temperature Grade	INDUSTRIAL
Interface	CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size	256kB
Oscillator Type	Internal
Number of I/O	53
Speed	70 MIPs
RAM Size	16K x 16
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	256KB 85.5K x 24
Connectivity	CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max	150 mA
Bit Size	16
Data Converter	A/D 16x10b/12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	5
ROM (words)	87381
EEPROM Size	--
On Chip Program ROM Width	24
Format	FLOATING-POINT
RAM (words)	16384
RAM (bytes)	32768
ROM Programmability	FLASH
Length	9mm
Height Seated (Max)	1mm
Width	9 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

DSPIC33EP256GP506T-I/MR Product Details

DSPIC33EP256GP506T-I/MR Overview

This Microcontroller comes in a 64-VFQFN Exposed Pad package. This Microcontroller has 53 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 16-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~85°C TA Operating Temperature. Microcontroller runs in dsPIC™ 33EP Series. The size of the program memory of Microcontroller is 256KB 85.5K x 24. MCU is powered by dsPIC Core Processor. The device belongs to MICROCONTROLLER uPs/uCs/Peripheral ICs Type. The MCU has a number of 64 terminals. Microcontroller comes with 16 bit size. The component always operates in 3.3V supply voltage. MCU chip has YES DMA channels. The part owns 256kB memory size. You can find alternatives through the base part number DSPIC33EP256GP506. MCU's frequency is 70MHz. The device works in YES PWM channels. The pin number of the component remains 64. It has 5 timers/counters. It counts 64 pins.
