Name: DSPIC33EP16GS505-E/PT
Brand: Microchip Technology
SKU: DSPIC33EP16GS505-E/PT
Price: 4.19000 USD
Availability: InStock

new-10%

DSPIC33EP16GS505-E/PT

Manufacturer part number:DSPIC33EP16GS505-E/PT

Manufacturer:Microchip Technology

Description:16KB 16K x 8 FLASH dsPIC 16-Bit Microcontroller Automotive, AEC-Q100, dsPIC™ 33EP Series DSPIC33EP16GS505 3.3V 48-TQFP Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33EP16GS505-E/PT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	17 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Mounting Type	Surface Mount
Package / Case	48-TQFP Exposed Pad
Surface Mount	YES
Supplier Device Package	48-TQFP-EP (7x7)
Mounting Style	SMD/SMT
Data Converters	A/D 19x12b, D/A 1x12b
Number of I/Os	35
RoHS	Compliant
Qualification	AEC-Q100
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Interface Type	I2C, SPI, UART
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	dsPIC
Package	Tray
Base Product Number	DSPIC33EP16GS505
Mfr	Microchip Technology
Product Status	Active
Operating Temperature	-40°C~125°C TA
Packaging	Tray
Series	Automotive, AEC-Q100, dsPIC™ 33EP
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	48
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125 °C
Min Operating Temperature	-40 °C
HTS Code	8542.31.00.01
Subcategory	Embedded Processors & Controllers
Terminal Position	QUAD
Terminal Form	GULL WING
Supply Voltage	3.3V
Terminal Pitch	0.5mm
Base Part Number	DSPIC33EP16GS505
JESD-30 Code	S-PQFP-G48
Operating Supply Voltage	3.3 V
Supply Voltage-Max (Vsup)	3.6V
Supply Voltage-Min (Vsup)	3V
Interface	I2C, IrDA, LIN, SPI, UART, USART
Memory Size	16kB
Oscillator Type	Internal
Number of I/O	35
Speed	60 MIPs
RAM Size	2K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency	60MHz
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	16KB 16K x 8
Connectivity	I2C, IrDA, LINbus, SPI, UART/USART
Bit Size	16
Data Converter	A/D 19x12b; D/A 1x12b
Has ADC	YES
DMA Channels	NO
Data Bus Width	16 bit
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	5 Timer
Product Type	DSP - Digital Signal Processors & Controllers
ROM (words)	16384
Core Architecture	dsPIC
EEPROM Size	--
On Chip Program ROM Width	8
Screening Level	AEC-Q100; TS 16949
Number of Cores	1 Core
Product	DSCs
Product Category	Digital Signal Processors & Controllers - DSP, DSC
Length	7mm
Height Seated (Max)	1.2mm
Width	7mm
RoHS Status	ROHS3 Compliant

DSPIC33EP16GS505-E/PT Product Details

DSPIC33EP16GS505-E/PT Overview
