Name: DSPIC33CK32MP502-I/2N
Brand: Microchip Technology
SKU: DSPIC33CK32MP502-I/2N
Price: 3.40000 USD
Availability: InStock

new-10%

DSPIC33CK32MP502-I/2N

Manufacturer part number:DSPIC33CK32MP502-I/2N

Manufacturer:Microchip Technology

Description:32KB 32K x 8 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 33CK Series DSPIC33CK32MP502 3.3V 28-UQFN Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33CK32MP502-I/2N Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	28-UQFN Exposed Pad
Surface Mount	YES
Supplier Device Package	28-UQFN (6x6)
Number of Terminals	28
Mounting Style	SMD/SMT
Qualification	AEC-Q100
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	CAN, I2C, I2S, SPI, UART
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	dsPIC
RoHS	Details
Package	Tube
Base Product Number	DSPIC33CK32MP502
Mfr	Microchip Technology
Data Converters	A/D 12x12b; D/A 3x12b
Product Status	Active
Package Shape	SQUARE
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	dsPIC™ 33CK
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
Subcategory	Embedded Processors & Controllers
Terminal Position	QUAD
Terminal Form	NO LEAD
Supply Voltage	3.3V
Terminal Pitch	0.65mm
Reach Compliance Code	compliant
Base Part Number	DSPIC33CK32MP502
JESD-30 Code	S-PQCC-N28
Operating Supply Voltage	3 V to 3.6 V
Supply Voltage-Max (Vsup)	3.6V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	3V
Oscillator Type	Internal
Number of I/O	21
Speed	100MHz
RAM Size	8K x 8
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Clock Frequency	64MHz
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	32KB 32K x 8
Connectivity	CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Bit Size	16
Data Converter	A/D 12x12b; D/A 3x12b
Data Bus Width	16 bit
Seated Height-Max	0.55 mm
Number of Timers/Counters	1 Timer
Product Type	DSP - Digital Signal Processors & Controllers
EEPROM Size	-
On Chip Program ROM Width	8
Boundary Scan	YES
Low Power Mode	YES
Format	FIXED POINT
Integrated Cache	NO
RAM (words)	8192
Number of Timers	1
ROM Programmability	FLASH
Number of Cores	1 Core
Number of External Interrupts	4
Barrel Shifter	YES
Internal Bus Architecture	SINGLE
On Chip Data RAM Width	8
Number of DMA Channels	4
Product	DSCs
Product Category	Digital Signal Processors & Controllers - DSP, DSC
Length	6mm
Height Seated (Max)	0.55mm
Width	6mm

DSPIC33CK32MP502-I/2N Product Details

DSPIC33CK32MP502-I/2N Overview

The package is 28-UQFN Exposed Pad-shaped. There are 21 I/Os. In the case of the IC chip, the type of mounting is Surface Mount. Microcontroller is based on the 16-Bit core architecture. The type of program memory it uses is FLASH. Temperatures in the range of -40°C~85°C TA are operated by this Microcontroller. It is part of the dsPIC™ 33CK series of electrical components. Having a size of 32KB 32K x 8, Microcontroller has a program memory of X bytes. A dsPIC Core Processor is at the core of this Microcontroller. This device belongs to the MICROCONTROLLER uPs/uCs/Peripheral ICs category. IC Chip 28 has 28 terminations. 16-bits are used for its size. IC Chip has 3.3V volt supply outputs. Using the base part number DSPIC33CK32MP502, you will be able to find alternatives for the part. In total, there are 1 Timer timers/counters on the device. As far as its frequency goes, it operates according to a 64MHz clock. A total of 4 external interrupts are included in the Microcontroller as well. IC chip bits total 1.
