Name: DSPIC30F3012-20I/SO
Brand: Microchip Technology
SKU: DSPIC30F3012-20I/SO
Price: 5.53000 USD
Availability: InStock

new-10%

DSPIC30F3012-20I/SO

Manufacturer part number:DSPIC30F3012-20I/SO

Manufacturer:Microchip Technology

Description:24KB 8K x 24 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 30F Series DSPIC30F3012 18 Pin 20MHz 5V 18-SOIC (0.295, 7.50mm Width)

Case Package:SOT-23

Datasheet:DSPIC30F3012-20I/SO Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	1 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	18-SOIC (0.295, 7.50mm Width)
Surface Mount	YES
Number of Pins	18
Supplier Device Package	18-SOIC
Number of Terminals	18
Mounting Style	SMD/SMT
Interfaces	I2C/SPI/UART
Instruction Set Architecture	RISC
Clock Freq	20(MHz)
Operating Temperature Classification	Industrial
Package Type	SOIC W
Number of Timers - General Purpose	3
Operating Temp Range	-40C to 85C
# I/Os (Max)	12
Interface Type	I2C/SPI/UART
Total Internal Ram Size	2KB(kB)
Device Core Size	16(b)
Operating Supply Voltage (Max)	5.5(V)
Operating Supply Voltage (Typ)	3.3/5(V)
Rad Hardened	No
Operating Supply Voltage (Min)	2.5(V)
Programmable	Yes
Mounting	Surface Mount
Data Converters	A/D 8x12b
Schedule B	8542310000, 8542310000/8542310000/8542310000/8542310000/8542310000
Number of I/Os	12
RoHS	Compliant
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	dsPIC
Package	Tube
Base Product Number	DSPIC30F3012
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Number of I/O Lines	12
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	dsPIC™ 30F
Published	2006
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	18
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Additional Feature	ALSO OPERATES AT 2.5V SUPPLY AT 7.5MHZ
HTS Code	8542.31.00.01
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	5V
Terminal Pitch	1.27 mm
Reach Compliance Code	compliant
Frequency	20MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC30F3012
Pin Count	18
JESD-30 Code	R-PDSO-G18
Qualification Status	Not Qualified
Operating Temperature (Max)	85C
Operating Temperature (Min)	-40C
Operating Supply Voltage	2.5 V to 5.5 V
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5 V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	4.5V
Interface	I2C, SPI, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	2.5 V
Memory Size	24kB
Oscillator Type	Internal
Number of I/O	12
Speed	20 MIPS
RAM Size	2K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2.5V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	16
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	24KB 8K x 24
Connectivity	I2C, SPI, UART/USART
Bit Size	16
Data Converter	A/D 8x12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	2.64 mm
Number of Timers/Counters	3
Product Type	DSP - Digital Signal Processors & Controllers
Density	192 kb
ROM (words)	8192
Core Architecture	dsPIC
EEPROM Size	1K x 8
On Chip Program ROM Width	24
Max Frequency	20 MHz
Number of A/D Converters	1
Number of Programmable I/O	12
Format	FIXED-POINT
RAM (words)	2048
Number of UART Channels	1
RAM (bytes)	2048
Number of ADC Channels	8
ROM Programmability	FLASH
Number of Cores	1 Core
Number of PWM Channels	2
Number of I2C Channels	1
Number of SPI Channels	1
Product	DSCs
Product Category	Digital Signal Processors & Controllers - DSP, DSC
Device Core	dsPIC
Height	2.35mm
Length	17.9mm
Width	7.5mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

DSPIC30F3012-20I/SO Product Details

DSPIC30F3012-20I/SO Overview

In a 18-SOIC (0.295, 7.50mm Width) package, the MCU is available. 12 I/Os are available. The Microcontroller has a mounting type of Surface Mount, which indicates that it is mounted conveniently. The 16-Bit core is the core of the MCU. There is a FLASH type of memory for its program. There is a temperature range of -40°C~85°C TA that is operated by this Microcontroller. dsPIC™ 30F series components make up this electrical component. 24KB 8K x 24 is the size of its program memory. A dsPIC Core processor is used to power the device. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 18 is the number of terminations on the IC chip that are present. This part works in a 16-bit manner. There is a 5V volt supply output on the chip. DMA channels number NO. 24kB is the memory size of the part. The base part number DSPIC30F3012 can be used to find alternatives. The efficiency of this device can be improved when operating at a frequency of 20MHz. The device works in YES PWM channels. Located on the chip are 18 pins. The clock has 3 timers or counters on it. There are 18 pins on it. It has built-in FLASH memory. There is an integrated dsPIC core architecture in it. It programs in 12 Programmable I/O. I would like to mention a few additional features such as ALSO OPERATES AT 2.5V SUPPLY AT 7.5MHZ in order to name a few. 1 UART channels are available on it. A total of 8 channels of ADC are available on this device. The MCU has 1 A/D converters. This Microcontroller is possible to have 16 bits in a chip. The device uses 2 PWM channels. There are 1 I2C channels included in the part, which has been designed for the purpose.
