Name: ATTINY461-15MAZ
Brand: Microchip Technology
SKU: ATTINY461-15MAZ
Availability: InStock

new-10%

ATTINY461-15MAZ

Manufacturer part number:ATTINY461-15MAZ

Manufacturer:Microchip Technology

Description:4KB 2K x 16 FLASH AVR 8-Bit Microcontroller Automotive, AEC-Q100, AVR® ATtiny Series ATTINY461 20 Pin 16MHz 5V 20-WFQFN Exposed Pad

Case Package:SOT-23

Datasheet:ATTINY461-15MAZ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-WFQFN Exposed Pad
Surface Mount	YES
Number of Pins	20
Supplier Device Package	20-QFN (4x4)
Number of Terminals	20
Interfaces	SPI
Data Converters	A/D 11x10b
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATTINY461
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	16
Operating Temperature	-40°C~125°C TA
Packaging	Tape & Reel (TR)
Series	Automotive, AEC-Q100, AVR® ATtiny
Published	1997
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	20
Additional Feature	OPERATES AT 2.7 V MINIMUM SUPPLY AT 8 MHZ
Terminal Position	QUAD
Terminal Form	NO LEAD
Supply Voltage	5V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	16MHz
Base Part Number	ATTINY461
JESD-30 Code	S-XQCC-N20
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5V
Temperature Grade	AUTOMOTIVE
Supply Voltage-Min (Vsup)	4.5V
Interface	SPI
Memory Size	4kB
Oscillator Type	Internal
Number of I/O	16
Speed	16MHz
RAM Size	256 x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	4KB 2K x 16
Connectivity	USI
Supply Current-Max	10 mA
Bit Size	8
Data Converter	A/D 11x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	0.8 mm
Number of Timers/Counters	2
ROM (words)	4096
EEPROM Size	256 x 8
CPU Family	AVR RISC
Screening Level	AEC-Q100
RAM (bytes)	256
ROM Programmability	FLASH
Device Core	AVR
Length	4mm
Height Seated (Max)	0.8mm
Width	4 mm
RoHS Status	ROHS3 Compliant

ATTINY461-15MAZ Product Details

ATTINY461-15MAZ Overview

20-WFQFN Exposed Pad-packages are available. There are 16 I/O ports on this device. Device mounting type Surface Mount is the type of mounting that the Microcontroller uses. There is a 8-Bit core at the core of this MCU. There is a type of program memory called FLASH in the Microcontroller. There is a temperature range of -40°C~125°C TA for this Microcontroller. An electrical component of this type belongs to the Automotive, AEC-Q100, AVR® ATtiny series. This program memory has a size of 4KB 2K x 16, which indicates what the size of the program memory is. AVR Core processors are used in MCU. Devices of this type belong to the MICROCONTROLLER, RISC power supply/socket/peripheral ICs category. This chip has a total of 20 terminations on MCU chip. You get a 8-bit size. This Microcontroller chip is powered by 5V volts. There are NO DMA channels on this Microcontroller chip. The part has a memory size of 4kB. The base part number ATTINY461 provides alternatives. This device is extremely efficient when operated at a frequency of 16MHz. Using the PWM channel YES, the device works with the motor. In this chip, 20 pins can be accessed. Using the timer/counter system, it has 2 timers/counters. In addition to this, the device is embedded with the the AVR RISC CPU family. Some of these features include OPERATES AT 2.7 V MINIMUM SUPPLY AT 8 MHZ, for example, as one example.
