Name: ATTINY45-15MT2
Brand: Microchip Technology
SKU: ATTINY45-15MT2
Availability: InStock

new-10%

ATTINY45-15MT2

Manufacturer part number:ATTINY45-15MT2

Manufacturer:Microchip Technology

Description:4KB 2K x 16 FLASH AVR 8-Bit Microcontroller Automotive, AEC-Q100, AVR® ATtiny Series ATTINY45 20 Pin 16MHz 5V 20-WFQFN Exposed Pad

Case Package:SOT-23

Datasheet:ATTINY45-15MT2 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-WFQFN Exposed Pad
Surface Mount	YES
Number of Pins	20
Supplier Device Package	20-WQFN (4x4)
Number of Terminals	20
Data Converters	A/D 4x10b
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATTINY45
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Operating Temperature	-40°C~150°C TA
Packaging	Tape & Reel (TR)
Series	Automotive, AEC-Q100, AVR® ATtiny
Published	2011
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	20
Additional Feature	ALSO OPERATES BY 2.7V MINIMUM SUPPLY AT 8 MHZ
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Supply Voltage	5V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	16MHz
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	ATTINY45
JESD-30 Code	S-XQCC-N20
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Temperature Grade	AUTOMOTIVE
Supply Voltage-Min (Vsup)	4.5V
Memory Size	4kB
Oscillator Type	Internal
Number of I/O	6
Speed	16MHz
RAM Size	256 x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	4KB 2K x 16
Connectivity	USI
Bit Size	8
Data Converter	A/D 4x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	NO
DAC Channels	NO
Seated Height-Max	0.8 mm
EEPROM Size	256 x 8
ROM Programmability	FLASH
Device Core	AVR
Length	4mm
Height Seated (Max)	0.8mm
Width	4 mm
RoHS Status	ROHS3 Compliant

ATTINY45-15MT2 Product Details

ATTINY45-15MT2 Overview

This Microcontroller comes in a 20-WFQFN Exposed Pad package. This Microcontroller has 6 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 8-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~150°C TA Operating Temperature. Microcontroller runs in Automotive, AEC-Q100, AVR® ATtiny Series. The size of the program memory of Microcontroller is 4KB 2K x 16. MCU is powered by AVR Core Processor. The device belongs to MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs Type. The MCU has a number of 20 terminals. Microcontroller comes with 8 bit size. The component always operates in 5V supply voltage. MCU chip has NO DMA channels. The part owns 4kB memory size. You can find alternatives through the base part number ATTINY45. MCU's frequency is 16MHz. The device works in NO PWM channels. The pin number of the component remains 20. To name a few, there are additional features like ALSO OPERATES BY 2.7V MINIMUM SUPPLY AT 8 MHZ.
