Name: ATTINY261-15XD
Brand: Microchip Technology
SKU: ATTINY261-15XD
Availability: InStock

new-10%

ATTINY261-15XD

Manufacturer part number:ATTINY261-15XD

Manufacturer:Microchip Technology

Description:2KB 1K x 16 FLASH AVR 8-Bit Microcontroller Automotive, AEC-Q100, AVR® ATtiny Series ATTINY261 20 Pin 16MHz 5V 20-TSSOP (0.173, 4.40mm Width)

Case Package:SOT-23

Datasheet:ATTINY261-15XD Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Mounting Type	Surface Mount
Package / Case	20-TSSOP (0.173, 4.40mm Width)
Surface Mount	YES
Number of Pins	20
Supplier Device Package	20-TSSOP
Number of Terminals	20
Interfaces	SPI
Instruction Set Architecture	RISC
Clock Freq	16(MHz)
Operating Temperature Classification	Automotive
Package Type	TSSOP
Number of Timers - General Purpose	2
Operating Temp Range	-40C to 150C
# I/Os (Max)	16
Interface Type	USI
Total Internal Ram Size	128B(kB)
Device Core Size	8(b)
Operating Supply Voltage (Max)	5.5(V)
Operating Supply Voltage (Typ)	3.3/5(V)
Rad Hardened	No
Operating Supply Voltage (Min)	2.7(V)
Programmable	Yes
Mounting	Surface Mount
Data Converters	A/D 11x10b
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATTINY261
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Number of I/O Lines	16
Operating Temperature	-40°C~150°C TA
Packaging	Tape & Reel (TR)
Series	Automotive, AEC-Q100, AVR® ATtiny
Published	2007
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	20
Additional Feature	ALSO OPERATES WITH 2.7V MIN @ 8MHZ
Terminal Position	DUAL
Terminal Form	GULL WING
Supply Voltage	5V
Terminal Pitch	0.65mm
Reach Compliance Code	compliant
Frequency	16MHz
Base Part Number	ATTINY261
Pin Count	20
JESD-30 Code	R-PDSO-G20
Operating Temperature (Max)	150C
Operating Temperature (Min)	-40C
Supply Voltage-Max (Vsup)	5.5V
Temperature Grade	AUTOMOTIVE
Supply Voltage-Min (Vsup)	4.5V
Memory Size	2kB
Oscillator Type	Internal
Number of I/O	16
Speed	16MHz
RAM Size	128 x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	2KB 1K x 16
Connectivity	USI
Bit Size	8
Data Converter	A/D 11x10b
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.1 mm
EEPROM Size	128 x 8
On Chip Program ROM Width	8
Screening Level	AEC-Q100; TS 16949
ROM Programmability	FLASH
Device Core	AVR
Length	6.5mm
Height Seated (Max)	1.1mm
Width	4.4 mm
RoHS Status	ROHS3 Compliant

ATTINY261-15XD Product Details
