Name: ATSAMS70Q20B-CFN
Brand: Microchip Technology
SKU: ATSAMS70Q20B-CFN
Price: 15.21000 USD
Availability: InStock

new

ATSAMS70Q20B-CFN

Manufacturer part number:ATSAMS70Q20B-CFN

Manufacturer:Microchip Technology

Description:1MB 1M x 8 FLASH ARM® Cortex®-M7 32-Bit Microcontroller SAM S70 Series ATSAMS70Q 1.2V 144-LFBGA

Case Package:SOT-23

Datasheet:ATSAMS70Q20B-CFN Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	144-LFBGA
Surface Mount	YES
Supplier Device Package	144-LFBGA (10x10)
Number of Terminals	144
Mounting Style	SMD/SMT
Interfaces	Serial I2C/SPI/UART/
Data Converters	A/D 10x12b; D/A 2x12b
MSL	-
DAC Resolution	12 bit
Number of I/Os	114 I/O
Maximum Operating Temperature	+ 105 C
Minimum Operating Temperature	- 40 C
Interface Type	SPI, UART, USART, USB
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
RoHS	Details
Package	Tray
Base Product Number	ATSAMS70
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	114
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	SAM S70
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	144
Subcategory	Microcontrollers - MCU
Terminal Position	BOTTOM
Terminal Form	BALL
Supply Voltage	1.2V
Terminal Pitch	0.4mm
Reach Compliance Code	compliant
Base Part Number	ATSAMS70Q
JESD-30 Code	S-PBGA-B144
Supply Voltage-Max (Vsup)	1.32V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.08V
Oscillator Type	Internal
Number of I/O	75
Speed	300MHz
RAM Size	384K x 8
Voltage - Supply (Vcc/Vdd)	1.62V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M7
Peripherals	Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency	20MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	1MB 1M x 8
Connectivity	CANbus, Ethernet, I2C, IrDA, LINbus, SPI, UART/USART, USB
Bit Size	32
Data Converter	A/D 10x12b; D/A 2x12b
Has ADC	YES
DMA Channels	YES
Data Bus Width	32 Bit
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	0.6 mm
Number of Timers/Counters	4 Timer
Address Bus Width	24
Product Type	ARM Microcontrollers - MCU
EEPROM Size	--
On Chip Program ROM Width	8
Screening Level	TS 16949
External Data Bus Width	16
Number of ADC Channels	24 Channel
ROM Programmability	FLASH
Product	MCU+DSP+FPU
Product Category	ARM Microcontrollers - MCU
Device Core	ARM Cortex-M7F
Length	6mm
Height Seated (Max)	0.6mm
Width	6mm

ATSAMS70Q20B-CFN Product Details

ATSAMS70Q20B-CFN Overview

In a 144-LFBGA package, the MCU is available. 75 I/Os are available. The Microcontroller has a mounting type of Surface Mount, which indicates that it is mounted conveniently. The 32-Bit core is the core of the MCU. There is a FLASH type of memory for its program. There is a temperature range of -40°C~105°C TA that is operated by this Microcontroller. SAM S70 series components make up this electrical component. 1MB 1M x 8 is the size of its program memory. A ARM® Cortex®-M7 Core processor is used to power the device. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 144 is the number of terminations on the IC chip that are present. This part works in a 32-bit manner. There is a 1.2V volt supply output on the chip. DMA channels number YES. The base part number ATSAMS70Q can be used to find alternatives. The device works in YES PWM channels. The clock has 4 Timer timers or counters on it. A 20MHz-clock frequency is used to operate it. A total of 24 Channel channels of ADC are available on this device.
