Name: ATSAME53N19A-AU
Brand: Microchip Technology
SKU: ATSAME53N19A-AU
Price: 7.92000 USD
Availability: InStock

new-10%

ATSAME53N19A-AU

Manufacturer part number:ATSAME53N19A-AU

Manufacturer:Microchip Technology

Description:512KB 512K x 8 FLASH ARM® Cortex®-M4F 32-Bit Microcontroller SAM E53 Series ATSAME53N 3.3V 100-TQFP

Case Package:SOT-23

Datasheet:ATSAME53N19A-AU Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mounting Type	Surface Mount
Package / Case	100-TQFP
Surface Mount	YES
Supplier Device Package	100-TQFP (14x14)
Number of Terminals	100
Mounting Style	SMD/SMT
Interfaces	Ethernet/I2S/SPI/USB
Data Converters	A/D 28x12b, D/A 2x12b
Package	Tray
Base Product Number	ATSAME53
Mfr	Microchip Technology
Product Status	Active
DAC Resolution	12 bit
Qualification	AEC-Q100
Number of I/Os	81 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	I2C, LIN, Serial, SPI, USART
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
RoHS	Details
Package Shape	SQUARE
Number of I/O Lines	81
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	SAM E53
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
Terminal Finish	Matte Tin (Sn)
Subcategory	Microcontrollers - MCU
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Supply Voltage	3.3V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	ATSAME53N
JESD-30 Code	S-PQFP-G100
Supply Voltage-Max (Vsup)	3.63V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.71V
Oscillator Type	Internal
Number of I/O	81
Speed	120MHz
RAM Size	192K x 8
Voltage - Supply (Vcc/Vdd)	1.71V~3.63V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M4F
Peripherals	Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency	48MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	512KB 512K x 8
Connectivity	EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD, QSPI, SPI, UART/USART, USB
Bit Size	32
Data Converter	A/D 28x12b; D/A 2x12b
Has ADC	YES
DMA Channels	YES
Data Bus Width	32 Bit
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	1.2 mm
Product Type	ARM Microcontrollers - MCU
EEPROM Size	--
On Chip Program ROM Width	8
Screening Level	ISO/TS-16949
Number of ADC Channels	28 Channel
ROM Programmability	FLASH
Product	MCU+FPU
Product Category	ARM Microcontrollers - MCU
Device Core	ARM Cortex M4F
Length	14mm
Height Seated (Max)	1.2mm
Width	14mm
RoHS Status	ROHS3 Compliant

ATSAME53N19A-AU Product Details

ATSAME53N19A-AU Overview

The package has a 100-TQFP shape. With 81 I/Os, it's pretty good. The Microcontroller's mounting type is Surface Mount and this IC chip has the following features. As the name implies, this Microcontroller is based on the 32-Bit core. As far as its program memory type is concerned, it is FLASH. Temperatures within -40°C~85°C TA range are measured by this Microcontroller. The SAM E53 series is comprised of this electrical component. The electronic part has a program memory size of 512KB 512K x 8. There's a ARM® Cortex®-M4F Core Processor inside. The IC chip fits into the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. There are 100 terminations on the IC chip. 32-bits are the size of the data that comes with MCU. A 3.3V volt supply is provided by the Microcontroller chip. In addition to that, MCU chip has YES DMA channels. It is possible to find alternatives to the base part number ATSAME53N by using the part number search tool. There are a total of YES channels in the device. The clock frequency is 48MHz. The ADC channels on this device total 28 Channel in number.
