Name: ATSAMC21J18A-UUT
Brand: Microchip Technology
SKU: ATSAMC21J18A-UUT
Availability: InStock

new-10%

ATSAMC21J18A-UUT

Manufacturer part number:ATSAMC21J18A-UUT

Manufacturer:Microchip Technology

Description:256KB 256K x 8 FLASH ARM® Cortex®-M0+ 32-Bit Microcontroller SAM C21 Series 5V 56-UFBGA, WLCSP

Case Package:SOT-23

Datasheet:ATSAMC21J18A-UUT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	29 Weeks
Mounting Type	Surface Mount
Package / Case	56-UFBGA, WLCSP
Surface Mount	YES
Supplier Device Package	56-WLCSP (3.17x3.44)
Number of Terminals	56
Mounting Style	SMD/SMT
Package	Tape & Reel (TR)
Base Product Number	ATSAMC21
Mfr	Microchip Technology
Data Converters	A/D 20x12b Sigma-Delta; D/A 1x10b
Product Status	Active
DAC Resolution	10 bit
Qualification	AEC-Q100
Number of I/Os	52 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	I2C, LIN, PMBus, Serial, SPI, USART
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package Shape	RECTANGULAR
Number of I/O Lines	44
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	SAM C21
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	56
HTS Code	8542.31.00.01
Subcategory	Microcontrollers - MCU
Terminal Position	BOTTOM
Terminal Form	BALL
Supply Voltage	5V
Terminal Pitch	0.4mm
Reach Compliance Code	compliant
JESD-30 Code	R-PBGA-B56
Supply Voltage-Max (Vsup)	5.5V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	2.7V
Oscillator Type	Internal
Number of I/O	44
Speed	48MHz
RAM Size	32K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M0+
Peripherals	Brown-out Detect/Reset, DMA, POR, WDT
Clock Frequency	48MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	256KB 256K x 8
Connectivity	CANbus, I2C, LINbus, SPI, UART/USART
Bit Size	32
Data Converter	A/D 20x12b Sigma-Delta; D/A 1x10b
Has ADC	YES
DMA Channels	YES
Data Bus Width	32 bit
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	0.483 mm
Product Type	ARM Microcontrollers - MCU
EEPROM Size	-
On Chip Program ROM Width	8
Screening Level	TS 16949
Number of ADC Channels	20 Channel
ROM Programmability	FLASH
Product	MCU
Product Category	ARM Microcontrollers - MCU
Height Seated (Max)	0.483mm
Width	3.17mm
Length	3.444 mm

ATSAMC21J18A-UUT Product Details

ATSAMC21J18A-UUT Overview

A 56-UFBGA, WLCSP package is included. In total, it has 44 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 32-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~85°C TA. SAM C21 series components belong to this electrical component. Its program memory size is 256KB 256K x 8. There is a ARM® Cortex®-M0+ Core Processor inside MCU that provides this device with its power. MICROCONTROLLER, RISC uPs, uCs, and peripheral ICs make up the Microcontroller. Microcontroller is known that the chip has 56 terminations in total. The part works on a 32-bit basis. An output voltage of 5V volts is available for this Microcontroller chip. The Microcontroller chip has YES DMA channels. In order for the device to work with the motor, it utilizes the PWM channel YES. In order for it to function, it needs to have a clock frequency of 48MHz. In total, there are 20 Channel channels for the ADC on this board.
