Name: ATSAM4SA16CB-CN
Brand: Microchip Technology
SKU: ATSAM4SA16CB-CN
Price: 10.19000 USD
Availability: InStock

new

ATSAM4SA16CB-CN

Manufacturer part number:ATSAM4SA16CB-CN

Manufacturer:Microchip Technology

Description:1MB 1M x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller SAM4S Series ATSAM4SA16 1.2V 100-TFBGA

Case Package:SOT-23

Datasheet:ATSAM4SA16CB-CN Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	100-TFBGA
Surface Mount	YES
Supplier Device Package	100-TFBGA (9x9)
Number of Terminals	100
Mounting Style	SMD/SMT
Data Converters	A/D 16x12b, D/A 2x12b
Package	Tray
Base Product Number	ATSAM4SA
Mfr	Microchip Technology
Product Status	Active
DAC Resolution	12 bit
Number of I/Os	79 I/O
Maximum Operating Temperature	+ 105 C
Minimum Operating Temperature	- 40 C
Interface Type	I2C, I2S, RS-485, SPI, UART, USART, USB
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package Shape	SQUARE
Number of I/O Lines	79
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	SAM4S
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
Subcategory	Microcontrollers - MCU
Terminal Position	BOTTOM
Terminal Form	BALL
Supply Voltage	1.2V
Terminal Pitch	0.8mm
Reach Compliance Code	compliant
Base Part Number	ATSAM4SA16
JESD-30 Code	S-PBGA-B100
Supply Voltage-Max (Vsup)	1.32V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.08V
Oscillator Type	Internal
Number of I/O	79
Speed	120MHz
RAM Size	160K x 8
Voltage - Supply (Vcc/Vdd)	1.62V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M4
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Clock Frequency	20MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	1MB 1M x 8
Connectivity	EBI/EMI, I2C, IrDA, Memory Card, SPI, SSC, UART/USART, USB
Bit Size	32
Data Converter	A/D 16x12b; D/A 2x12b
Has ADC	YES
DMA Channels	YES
Data Bus Width	32 bit
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	1.1 mm
Number of Timers/Counters	2 Timer
Address Bus Width	24
Product Type	ARM Microcontrollers - MCU
EEPROM Size	--
On Chip Program ROM Width	8
External Data Bus Width	8
Number of ADC Channels	16 Channel
ROM Programmability	FLASH
Product	MCU
Product Category	ARM Microcontrollers - MCU
Length	9mm
Height Seated (Max)	1.1mm
Width	9mm
RoHS Status	ROHS3 Compliant

ATSAM4SA16CB-CN Product Details

ATSAM4SA16CB-CN Overview

A 100-TFBGA package is included. In total, it has 79 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 32-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~105°C TA. SAM4S series components belong to this electrical component. Its program memory size is 1MB 1M x 8. There is a ARM® Cortex®-M4 Core Processor inside MCU that provides this device with its power. MICROCONTROLLER, RISC uPs, uCs, and peripheral ICs make up the Microcontroller. Microcontroller is known that the chip has 100 terminations in total. The part works on a 32-bit basis. An output voltage of 1.2V volts is available for this Microcontroller chip. The Microcontroller chip has YES DMA channels. ATSAM4SA16 is the base part number that you can use to find alternatives. In order for the device to work with the motor, it utilizes the PWM channel YES. A total of 2 Timer timers/counters are included in the package. In order for it to function, it needs to have a clock frequency of 20MHz. In total, there are 16 Channel channels for the ADC on this board.
