Name: ATSAM4SA16CA-ANR
Brand: Microchip Technology
SKU: ATSAM4SA16CA-ANR
Availability: InStock

new-10%

ATSAM4SA16CA-ANR

Manufacturer part number:ATSAM4SA16CA-ANR

Manufacturer:Microchip Technology

Description:1MB 1M x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller SAM4S Series ATSAM4SA16 120MHz 1.2V 100-LQFP

Case Package:SOT-23

Datasheet:ATSAM4SA16CA-ANR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	100-LQFP
Surface Mount	YES
Supplier Device Package	100-LQFP (14x14)
Number of Terminals	100
Data Converters	A/D 16x12b, D/A 2x12b
Package	Tray
Base Product Number	ATSAM4SA
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	79
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	SAM4S
Published	2014
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
ECCN Code	3A991.A.2
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	GULL WING
Supply Voltage	1.2V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	120MHz
Base Part Number	ATSAM4SA16
JESD-30 Code	S-PQFP-G100
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	1.32V
Power Supplies	1.2V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.08V
Interface	EBI/EMI, I2C, IrDA, SPI, UART, USART, USB
Memory Size	1MB
Oscillator Type	Internal
Number of I/O	79
Speed	120MHz
RAM Size	160K x 8
Voltage - Supply (Vcc/Vdd)	1.62V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M4
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	1MB 1M x 8
Connectivity	EBI/EMI, I2C, IrDA, Memory Card, SPI, SSC, UART/USART, USB
Supply Current-Max	25 mA
Bit Size	32
Data Converter	A/D 16x12b; D/A 2x12b
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	1.6 mm
Address Bus Width	24
ROM (words)	1048576
Core Architecture	ARM
EEPROM Size	--
CPU Family	CORTEX-M4
External Data Bus Width	8
RAM (bytes)	163840
ROM Programmability	FLASH
Length	14mm
Height Seated (Max)	1.6mm
Width	14mm
RoHS Status	ROHS3 Compliant

ATSAM4SA16CA-ANR Product Details

ATSAM4SA16CA-ANR Overview

There is a 100-LQFP package available. The board has 79 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 32-Bit core is used in order to power the IC chip. The type of memory it uses for its program is FLASH. -40°C~105°C TA is the temperature range at which this Microcontroller operates. SAM4S-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 1MB 1M x 8. Powered by a ARM® Cortex®-M4 Core processor. Microcontroller's a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. IC Chip terminations are 100. As a result, this Microcontroller comes with a 32-bit size. Input voltage for the chip is 1.2V volts. A total of YES DMA channels are available. This IC part has a memory size of 1MB. There are a number of alternatives to the base part number ATSAM4SA16 that you can find. Performing well when operated at frequency 120MHz can be achieved. Using YES PWM channels, the device works. The device is powered by the the CORTEX-M4 CPU family that is embedded in it. The CPU is based on ARM cores.
