Name: ATSAM4LC2BA-UUR
Brand: Microchip Technology
SKU: ATSAM4LC2BA-UUR
Availability: InStock

new-10%

ATSAM4LC2BA-UUR

Manufacturer part number:ATSAM4LC2BA-UUR

Manufacturer:Microchip Technology

Description:128KB 128K x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller SAM4L Series ATSAM4LC2 48MHz 3.3V 64-XFBGA, WLCSP

Case Package:SOT-23

Datasheet:ATSAM4LC2BA-UUR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Plating	Copper, Silver, Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	64-XFBGA, WLCSP
Surface Mount	YES
Supplier Device Package	64-WLCSP (4.4x4.4)
Number of Terminals	64
Interfaces	I2C/SPI/UART/USART/U
Instruction Set Architecture	RISC
Clock Freq	48(MHz)
DAC Resolution	10
Operating Temperature Classification	Industrial
Package Type	WLCSP
Number of Timers - General Purpose	1
Operating Temp Range	-40C to 85C
# I/Os (Max)	43
Total Internal Ram Size	32KB(kB)
Device Core Size	32(b)
Operating Supply Voltage (Max)	3.6(V)
Operating Supply Voltage (Typ)	1.8/2.5/3.3(V)
Rad Hardened	No
Operating Supply Voltage (Min)	1.68(V)
Programmable	Yes
Mounting	Surface Mount
Data Converters	A/D 7x12b, D/A 1x10b
Package	Tape & Reel (TR)
Base Product Number	ATSAM4LC
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Number of I/O Lines	43
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	SAM4L
Published	2013
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
Terminal Position	BOTTOM
Terminal Form	BALL
Supply Voltage	3.3V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	48MHz
Base Part Number	ATSAM4LC2
Pin Count	64
JESD-30 Code	R-PBGA-B64
Qualification Status	Not Qualified
Operating Temperature (Max)	85C
Operating Temperature (Min)	-40C
Operating Supply Voltage	3.3V
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	1.8/3.3 V
Temperature Grade	INDUSTRIAL
Interface	I2C, IrDA, LIN, SPI, UART, USART, USB
Memory Size	128kB
Oscillator Type	Internal
Number of I/O	43
Speed	48MHz
RAM Size	32K x 8
Voltage - Supply (Vcc/Vdd)	1.68V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M4
Peripherals	Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	128KB 128K x 8
Connectivity	I2C, IrDA, LINbus, SPI, UART/USART, USB
Supply Current-Max	18.24 mA
Bit Size	32
Data Converter	A/D 7x12b; D/A 1x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	32b
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	0.482 mm
Number of Timers/Counters	4
ROM (words)	131072
Core Architecture	ARM
EEPROM Size	--
CPU Family	CORTEX-M4
RAM (bytes)	32768
ROM Programmability	FLASH
Device Core	ARM Cortex M4
Width	4.314 mm
Length	4.434 mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

ATSAM4LC2BA-UUR Product Details

ATSAM4LC2BA-UUR Overview
