Name: ATSAM4E8EB-CN
Brand: Microchip Technology
SKU: ATSAM4E8EB-CN
Price: 11.89000 USD
Availability: InStock

new

ATSAM4E8EB-CN

Manufacturer part number:ATSAM4E8EB-CN

Manufacturer:Microchip Technology

Description:512KB 512K x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller SAM4E Series ATSAM4E 1.2V 144-LFBGA

Case Package:SOT-23

Datasheet:ATSAM4E8EB-CN Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mounting Type	Surface Mount
Package / Case	144-LFBGA
Surface Mount	YES
Supplier Device Package	144-LFBGA (10x10)
Number of Terminals	144
Mounting Style	SMD/SMT
Data Converters	A/D 16x12b, D/A 2x12b
Package	Tray
Base Product Number	ATSAM4E
Mfr	Microchip Technology
Product Status	Active
DAC Resolution	12 bit
Number of I/Os	117 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	I2C, SPI, UART, USART, USB
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package Shape	SQUARE
Number of I/O Lines	117
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	SAM4E
Published	2016
JESD-609 Code	e1
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	144
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory	Microcontrollers - MCU
Terminal Position	BOTTOM
Terminal Form	BALL
Supply Voltage	1.2V
Terminal Pitch	0.8mm
Reach Compliance Code	compliant
Base Part Number	ATSAM4E
JESD-30 Code	S-PBGA-B144
Supply Voltage-Max (Vsup)	1.32V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.08V
Oscillator Type	Internal
Number of I/O	117
Speed	120MHz
RAM Size	128K x 8
Voltage - Supply (Vcc/Vdd)	1.62V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M4
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Clock Frequency	20MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	512KB 512K x 8
Connectivity	CANbus, EBI/EMI, Ethernet, IrDA, SD, SPI, UART/USART, USB
Bit Size	32
Data Converter	A/D 16x12b; D/A 2x12b
Has ADC	YES
DMA Channels	YES
Data Bus Width	32 bit
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	1.4 mm
Number of Timers/Counters	9 Timer
Address Bus Width	24
Product Type	ARM Microcontrollers - MCU
ROM (words)	131072
EEPROM Size	--
On Chip Program ROM Width	32
CPU Family	CORTEX-M4F
Low Power Mode	YES
External Data Bus Width	8
RAM (words)	32768
RAM (bytes)	131072
Number of ADC Channels	24 Channel
Number of Timers	3
ROM Programmability	FLASH
On Chip Data RAM Width	32
Number of DMA Channels	4
Product	MCU
Product Category	ARM Microcontrollers - MCU
Length	10mm
Height Seated (Max)	1.4mm
Width	10mm
RoHS Status	ROHS3 Compliant

ATSAM4E8EB-CN Product Details

ATSAM4E8EB-CN Overview

There is a 144-LFBGA package available. The board has 117 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 32-Bit core is used in order to power the IC chip. The type of memory it uses for its program is FLASH. -40°C~105°C TA is the temperature range at which this Microcontroller operates. SAM4E-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 512KB 512K x 8. Powered by a ARM® Cortex®-M4 Core processor. Microcontroller's a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. IC Chip terminations are 144. As a result, this Microcontroller comes with a 32-bit size. Input voltage for the chip is 1.2V volts. A total of YES DMA channels are available. There are a number of alternatives to the base part number ATSAM4E that you can find. Using YES PWM channels, the device works. It comes with 9 Timer timers/counters that can be set up. The device is powered by the the CORTEX-M4F CPU family that is embedded in it. As far as the clock frequency is concerned, it operates at 20MHz clock speed. The device has a total of 24 Channel ADC channels in total. The total number of bits on a MCU chip is 3.
