Name: ATMEGA64L-8AJ
Brand: Microchip Technology
SKU: ATMEGA64L-8AJ
Availability: InStock

new-10%

ATMEGA64L-8AJ

Manufacturer part number:ATMEGA64L-8AJ

Manufacturer:Microchip Technology

Description:64KB 32K x 16 FLASH AVR 8-Bit Microcontroller AVR® ATmega Series ATMEGA64 3V 64-TQFP

Case Package:SOT-23

Datasheet:ATMEGA64L-8AJ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	64-TQFP
Surface Mount	YES
Supplier Device Package	64-TQFP (14x14)
Number of Terminals	64
Data Converters	A/D 8x10b
Package	Tray
Base Product Number	ATMEGA64
Mfr	Microchip Technology
Product Status	Obsolete
Package Shape	SQUARE
Manufacturer	Atmel Corporation
Number of I/O Lines	53
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	AVR® ATmega
Published	1997
JESD-609 Code	e3
Pbfree Code	Yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
Terminal Finish	MATTE TIN
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.8mm
Reach Compliance Code	compliant
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	ATMEGA64
Pin Count	64
JESD-30 Code	S-PQFP-G64
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	2.7V
Oscillator Type	Internal
Number of I/O	53
Speed	8MHz
RAM Size	4K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency	8MHz
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	64KB 32K x 16
Connectivity	I2C, SPI, UART/USART
Bit Size	8
Data Converter	A/D 8x10b
Has ADC	YES
DMA Channels	NO
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.2 mm
Address Bus Width	16
ROM (words)	32768
Core Architecture	AVR
EEPROM Size	2K x 8
On Chip Program ROM Width	16
External Data Bus Width	8
RAM (bytes)	4096
ROM Programmability	FLASH
Can	0
Clock Speed	16
Flash Memory	64
Adc Channels	8
Adc Resolution	10
Device Core	AVR
Length	14mm
Height Seated (Max)	1.2mm
Width	14mm
RoHS Status	ROHS3 Compliant

ATMEGA64L-8AJ Product Details

ATMEGA64L-8AJ Overview
