Name: ATMEGA644PA-ANR
Brand: Microchip Technology
SKU: ATMEGA644PA-ANR
Price: 7.37000 USD
Availability: InStock

new

ATMEGA644PA-ANR

Manufacturer part number:ATMEGA644PA-ANR

Manufacturer:Microchip Technology

Description:64KB 32K x 16 FLASH AVR 8-Bit Microcontroller AVR® ATmega Series ATMEGA644PA 44 Pin 20MHz 44-TQFP

Case Package:SOT-23

Datasheet:ATMEGA644PA-ANR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-TQFP
Surface Mount	YES
Number of Pins	44
Supplier Device Package	44-TQFP (10x10)
Number of Terminals	44
Mounting Style	SMD/SMT
Interfaces	I2C/SPI/USART
Data Converters	A/D 8x10b
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	AVR
RoHS	Details
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATMEGA644
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	32
Operating Temperature	-40°C~105°C TA
Packaging	Tape & Reel (TR)
Series	AVR® ATmega
Published	2008
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	44
Subcategory	Microcontrollers - MCU
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Terminal Pitch	0.8mm
Reach Compliance Code	compliant
Frequency	20MHz
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	ATMEGA644PA
JESD-30 Code	S-PQFP-G44
Operating Supply Voltage	5V
Temperature Grade	INDUSTRIAL
Interface	I2C, SPI, UART, USART
Memory Size	64kB
Oscillator Type	Internal
Number of I/O	32
Speed	20MHz
RAM Size	4K x 8
Voltage - Supply (Vcc/Vdd)	1.8V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	64KB 32K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	9 mA
Bit Size	8
Data Converter	A/D 8x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.2 mm
Number of Timers/Counters	3
Product Type	8-bit Microcontrollers - MCU
ROM (words)	32768
EEPROM Size	2K x 8
On Chip Program ROM Width	16
CPU Family	AVR RISC
Boundary Scan	YES
Low Power Mode	YES
Format	FIXED-POINT
Integrated Cache	NO
RAM (words)	4096
RAM (bytes)	4096
Number of Serial I/Os	2
Number of Timers	3
ROM Programmability	FLASH
Number of External Interrupts	3
On Chip Data RAM Width	8
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	AVR
Length	10mm
Height Seated (Max)	1.2mm
Width	10 mm
RoHS Status	ROHS3 Compliant

ATMEGA644PA-ANR Product Details
