Name: ATMEGA162V-1AC
Brand: Microchip Technology
SKU: ATMEGA162V-1AC
Availability: InStock

new-10%

ATMEGA162V-1AC

Manufacturer part number:ATMEGA162V-1AC

Manufacturer:Microchip Technology

Description:16KB 8K x 16 FLASH AVR 8-Bit Microcontroller AVR® ATmega Series ATMEGA162 3V 44-TQFP

Case Package:SOT-23

Datasheet:ATMEGA162V-1AC Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	44-TQFP
Surface Mount	YES
Supplier Device Package	44-TQFP (10x10)
Number of Terminals	44
Data Converters	--
Package	Tray
Base Product Number	ATMEGA162
Mfr	Microchip Technology
Product Status	Obsolete
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	35
Operating Temperature	0°C~70°C
Packaging	Tray
Series	AVR® ATmega
Published	1997
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	44
Terminal Finish	TIN LEAD
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	240
Supply Voltage	3V
Terminal Pitch	0.8mm
Reach Compliance Code	not_compliant
Time@Peak Reflow Temperature-Max (s)	30
Base Part Number	ATMEGA162
JESD-30 Code	S-PQFP-G44
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	2/3V
Temperature Grade	COMMERCIAL
Supply Voltage-Min (Vsup)	1.8V
Oscillator Type	Internal
Number of I/O	35
Speed	1MHz
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency	1MHz
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	16KB 8K x 16
Connectivity	EBI/EMI, SPI, UART/USART
Bit Size	8
Has ADC	NO
DMA Channels	NO
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.2 mm
Address Bus Width	16
ROM (words)	8192
EEPROM Size	512 x 8
CPU Family	AVR RISC
External Data Bus Width	8
RAM (bytes)	1024
ROM Programmability	FLASH
Length	10mm
Height Seated (Max)	1.2mm
Width	10mm
RoHS Status	Non-RoHS Compliant

ATMEGA162V-1AC Product Details

ATMEGA162V-1AC Overview

44-TQFP-packages are available. There are 35 I/O ports on this device. Device mounting type Surface Mount is the type of mounting that the Microcontroller uses. There is a 8-Bit core at the core of this MCU. There is a type of program memory called FLASH in the Microcontroller. There is a temperature range of 0°C~70°C for this Microcontroller. An electrical component of this type belongs to the AVR® ATmega series. This program memory has a size of 16KB 8K x 16, which indicates what the size of the program memory is. AVR Core processors are used in MCU. Devices of this type belong to the MICROCONTROLLER, RISC power supply/socket/peripheral ICs category. This chip has a total of 44 terminations on MCU chip. You get a 8-bit size. This Microcontroller chip is powered by 3V volts. There are NO DMA channels on this Microcontroller chip. The base part number ATMEGA162 provides alternatives. Using the PWM channel YES, the device works with the motor. In addition to this, the device is embedded with the the AVR RISC CPU family. It's got a 1MHz clock.
