Name: AT91RM9200-CI-002
Brand: Microchip Technology
SKU: AT91RM9200-CI-002
Availability: InStock

new-10%

AT91RM9200-CI-002

Manufacturer part number:AT91RM9200-CI-002

Manufacturer:Microchip Technology

Description:128KB 128K x 8 ROM ARM920T 16/32-Bit Microcontroller AT91 Series AT91RM9200 256-LFBGA

Case Package:SOT-23

Datasheet:AT91RM9200-CI-002 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	256-LFBGA
Surface Mount	YES
Supplier Device Package	256-BGA (15x15)
Number of Terminals	256
Data Converters	--
Package	Tray
Base Product Number	AT91RM9200
Mfr	Microchip Technology
Product Status	Obsolete
Package Shape	SQUARE
Manufacturer	Atmel Corporation
Number of I/O Lines	122
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	AT91
Published	1997
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
ECCN Code	3A001.A.3
Terminal Finish	Tin/Lead (Sn/Pb)
HTS Code	8542.31.00.01
Subcategory	Microcontrollers
Technology	CMOS
Terminal Position	BOTTOM
Terminal Form	BALL
Peak Reflow Temperature (Cel)	240
Terminal Pitch	0.8 mm
Reach Compliance Code	unknown
Base Part Number	AT91RM9200
Pin Count	256
JESD-30 Code	S-PBGA-B256
Qualification Status	Not Qualified
Power Supplies	1.8,3.3 V
Temperature Grade	INDUSTRIAL
Oscillator Type	Internal
Number of I/O	122
Speed	180MHz
RAM Size	48K x 8
Voltage - Supply (Vcc/Vdd)	1.65V~1.95V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM920T
Peripherals	POR
Program Memory Type	ROM
Core Size	16/32-Bit
Program Memory Size	128KB 128K x 8
Connectivity	EBI/EMI, Ethernet, I2C, Memory Card, SPI, SSC, UART/USART, USB
Supply Current-Max	24.5 mA
Bit Size	32
Has ADC	NO
DMA Channels	YES
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.25 mm
Address Bus Width	26
ROM (words)	131072
EEPROM Size	--
CPU Family	ARM7
External Data Bus Width	32
RAM (bytes)	16384
ROM Programmability	FLASH
Width	15 mm
Length	15 mm
RoHS Status	Non-RoHS Compliant

AT91RM9200-CI-002 Product Details

AT91RM9200-CI-002 Overview

There is a 256-LFBGA package available. The board has 122 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 16/32-Bit core is used in order to power the IC chip. The type of memory it uses for its program is ROM. -40°C~85°C TA is the temperature range at which this Microcontroller operates. AT91-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 128KB 128K x 8. Powered by a ARM920T Core processor. Microcontroller's a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. As a result, this Microcontroller comes with a 32-bit size. A total of YES DMA channels are available. There are a number of alternatives to the base part number AT91RM9200 that you can find. Using YES PWM channels, the device works. The pins counted are 256. The device is powered by the the ARM7 CPU family that is embedded in it.
