Name: AT89S52-24JU
Brand: Microchip Technology
SKU: AT89S52-24JU
Price: 4.15000 USD
Availability: InStock

new-10%

AT89S52-24JU

Manufacturer part number:AT89S52-24JU

Manufacturer:Microchip Technology

Description:8KB 8K x 8 FLASH 8051 8-Bit Microcontroller 89S Series AT89S52 44 Pin 24MHz 5V 44-LCC (J-Lead)

Case Package:SOT-23

Datasheet:AT89S52-24JU Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-LCC (J-Lead)
Surface Mount	YES
Number of Pins	44
Supplier Device Package	44-PLCC (16.59x16.59)
Number of Terminals	44
Mounting Style	SMD/SMT
Manufacturer Package Identifier	44J – PLCC
Interfaces	UART
Data Converters	--
Family Name	AT89
Dimensions	16.66 x 16.66 x 4.06mm
Typical Operating Supply Voltage	4 → 5.5 V
Package Type	PLCC
Maximum Operating Temperature	+85 °C
Minimum Operating Temperature	-40 °C
MSL	MSL 2 - 1 year
Qualification	-
Number of I/Os	32 I/O
Interface Type	UART
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
RoHS	Details
Package	Tube
Base Product Number	AT89S52
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	32
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	89S
Published	1997
JESD-609 Code	e3
Pbfree Code	Yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	44
Termination	SMD/SMT
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Applications	--
HTS Code	8542.31.00.01
Subcategory	Microcontrollers - MCU
Voltage - Supply	--
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	245
Supply Voltage	5V
Terminal Pitch	1.27 mm
Reach Compliance Code	unknown
Frequency	24MHz
Base Part Number	AT89S52
Pin Count	44
JESD-30 Code	S-PQCC-J44
Qualification Status	Not Qualified
Operating Supply Voltage	5V
Power Supplies	5 V
Temperature Grade	INDUSTRIAL
Interface	SPI, UART
Memory Size	8kB
Oscillator Type	Internal
Number of I/O	32
Speed	24MHz
RAM Size	256 x 8
Voltage - Supply (Vcc/Vdd)	4V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Number of Bits	8
Core Processor	8051
Peripherals	WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	8KB 8K x 8
Connectivity	UART/USART
Supply Current-Max	25 mA
Bit Size	8
Watchdog Timer	Yes
Access Time	24 μs
Has ADC	NO
DMA Channels	NO
Data Bus Width	8b
PWM Channels	NO
DAC Channels	NO
Seated Height-Max	4.572 mm
Number of Timers/Counters	3
Address Bus Width	8b
Product Type	8-bit Microcontrollers - MCU
Density	64 kb
ROM (words)	8192
Core Architecture	8051
EEPROM Size	--
On Chip Program ROM Width	8
CPU Family	8051
External Data Bus Width	8
RAM (bytes)	256
ROM Programmability	FLASH
Number of SPI Channels	1
Controller Series	--
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Clock Speed	24
Flash Memory	8
Device Core	8051
Height	4.572mm
Length	16.66mm
Width	16.662mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

AT89S52-24JU Product Details

AT89S52-24JU Overview

It comes in a 44-LCC (J-Lead) package. It has a number of 32I/Os. The Mounting Type of the device is Surface Mount. It is based on the 8-Bit. The It?ˉs Program Memory Type is FLASH. The device runs in -40??C~85??C TA Operating Temperature. It runs in 89S Series.

AT89S52-24JU Features

89S series
Base part number of AT89S52
44 Terminals
Based on the 8-Bit
Comes with 44 Pins

AT89S52-24JU Applications

There are a lot of Microchip Technology AT89S52-24JU Microcontroller applications. AT89S52-24JU MCU is usually applied for Measurement and control field, Consumer electronics products, Network communication, mobile communication, Office automation equipment and computer peripherals, Industrial control Instrumentation and process control, Agriculture, transportation, Navigation control, Network application, Metering & measurement, Day to day life, Safety, Medical instruments and Automobile industry.
