Name: AT80251G2D-RLTUL
Brand: Microchip Technology
SKU: AT80251G2D-RLTUL
Availability: InStock

new-10%

AT80251G2D-RLTUL

Manufacturer part number:AT80251G2D-RLTUL

Manufacturer:Microchip Technology

Description:Microcontroller 44 Pin 16MHz

Case Package:SOT-23

Datasheet:AT80251G2D-RLTUL Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	1 Week
Mount	Surface Mount
Surface Mount	YES
Number of Pins	44
Number of Terminals	44
Package Shape	SQUARE
Manufacturer	Atmel Corporation
Number of I/O Lines	32
JESD-609 Code	e3
Pbfree Code	Yes
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
HTS Code	8542.31.00.01
Subcategory	Microcontrollers
Technology	CMOS
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Terminal Pitch	0.8 mm
Reach Compliance Code	compliant
Frequency	16MHz
Pin Count	44
JESD-30 Code	S-PQFP-G44
Qualification Status	Not Qualified
Power Supplies	3/5 V
Temperature Grade	INDUSTRIAL
Interface	SPI, UART
Max Supply Voltage	5.5V
Min Supply Voltage	4.5V
Speed	16 MHz
RAM Size	1kB
Memory Type	ROMless
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Supply Current-Max	14 mA
Bit Size	16
Frequency (Max)	16MHz
Has ADC	NO
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.6 mm
Number of Timers/Counters	3
Address Bus Width	16
ROM (words)	0
Core Architecture	80C51
CPU Family	80251
External Data Bus Width	8
Number of Programmable I/O	32
RAM (bytes)	1024
Width	10 mm
Length	10 mm
RoHS Status	RoHS Compliant

AT80251G2D-RLTUL Product Details

AT80251G2D-RLTUL Overview

The IC chip fits into the MICROCONTROLLER uPs/uCs/Peripheral ICs category. 16-bits are the size of the data that comes with MCU. In addition to that, MCU chip has NO DMA channels. An effective performance can be achieved at a frequency of 16MHz. There are a total of YES channels in the device. It is possible to access the 44 pins on the chip. In total, it has 3 timers and counters in it. A total of 44 pins are included in the package. There are several CPUs that are embedded in the device, including the the 80251 CPU. The equipment on this page features ROMless memory technology. This device features a 80C51 core architecture. As far as the programmability is concerned, it has 32 Programmable I/Os.
