Name: AT32UC3B0512-Z2UES
Brand: Microchip Technology
SKU: AT32UC3B0512-Z2UES
Availability: InStock

new-10%

AT32UC3B0512-Z2UES

Manufacturer part number:AT32UC3B0512-Z2UES

Manufacturer:Microchip Technology

Description:Microcontroller 64 Pin 60MHz 1.8V VQFN

Case Package:SOT-23

Datasheet:AT32UC3B0512-Z2UES Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	VQFN
Surface Mount	YES
Number of Pins	64
JESD-609 Code	e3
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
Terminal Finish	MATTE TIN
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Subcategory	Microcontrollers
Technology	CMOS
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	1.8V
Terminal Pitch	0.5mm
Frequency	60MHz
Time@Peak Reflow Temperature-Max (s)	40
Qualification Status	Not Qualified
Temperature Grade	INDUSTRIAL
Max Supply Voltage	3.6V
Min Supply Voltage	1.65V
Memory Size	512kB
Number of I/O	44
RAM Size	96kB
Memory Type	FLASH
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Bit Size	32
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	YES
Number of Timers/Counters	3
ROM (words)	524288
Core Architecture	AVR
Length	9mm
Height Seated (Max)	1mm
Width	9mm
RoHS Status	Non-RoHS Compliant

AT32UC3B0512-Z2UES Product Details

AT32UC3B0512-Z2UES Overview

In a VQFN package, the MCU is available. 44 I/Os are available. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 64 is the number of terminations on the IC chip that are present. This part works in a 32-bit manner. There is a 1.8V volt supply output on the chip. DMA channels number YES. 512kB is the memory size of the part. The efficiency of this device can be improved when operating at a frequency of 60MHz. The device works in YES PWM channels. Located on the chip are 64 pins. The clock has 3 timers or counters on it. It has built-in FLASH memory. There is an integrated AVR core architecture in it.
