Name: 1N5272B-TP
Brand: Micro Commercial Co
SKU: 1N5272B-TP
Availability: InStock

new-10%

1N5272B-TP

Manufacturer part number:1N5272B-TP

Manufacturer:Micro Commercial Co

Description:ZENER DIODE 750Ohm ±5% 100nA @ 84V -55°C~150°C 2 Terminations DO-204AH, DO-35, Axial

Case Package:SOT-23

Datasheet:1N5272B-TP Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	DO-204AH, DO-35, Axial
Surface Mount	NO
Diode Element Material	SILICON
Operating Temperature	-55°C~150°C
Packaging	Tape & Reel (TR)
Published	2006
Tolerance	±5%
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
HTS Code	8541.10.00.50
Terminal Form	WIRE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Reach Compliance Code	compliant
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	1N5272
Pin Count	2
JESD-30 Code	O-LALF-W2
Qualification Status	Not Qualified
Number of Elements	1
Polarity	UNIDIRECTIONAL
Configuration	SINGLE
Power Dissipation-Max	0.5W
Diode Type	ZENER DIODE
Current - Reverse Leakage @ Vr	100nA @ 84V
Voltage - Forward (Vf) (Max) @ If	1.1V @ 200mA
Case Connection	ISOLATED
Power - Max	500mW
Impedance-Max	750Ohm
Reference Voltage	110V
Voltage - Zener (Nom) (Vz)	110V
Voltage Tol-Max	5%
Working Test Current	1.1mA
RoHS Status	RoHS Compliant

1N5272B-TP Product Details

1N5272B-TP Overview

This electrical device requires reverse leakage current of 100nA @ 84V.Tol is the maximum voltage that can be supplied (5%).The maximum voltage - Zener (Nom) is reduced to 110V during operation.Working test voltage should be set to 1.1mA for this device to operate.Zener single diode reaches 1.1V @ 200mA when Zener single diode is supplied wZener single diodeh the maximum voltage - Forward (Vf).
