Name: MAX3320TEAP+T
Brand: Maxim Integrated
SKU: MAX3320TEAP+T
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-SSOP (0.209, 5.30mm Width)
Number of Pins	20
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
Published	1997
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	20
ECCN Code	EAR99
Type	Transceiver
Terminal Finish	MATTE TIN
Voltage - Supply	3V~5.5V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Supply Voltage	3.3V
Terminal Pitch	0.65mm
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	MAX3320
Pin Count	20
Qualification Status	Not Qualified
Operating Supply Voltage	5.5V
Number of I/O	8
Nominal Supply Current	1mA
Propagation Delay	300 ns
Logic Function	Receiver, Transceiver
Data Rate	250kbps
Differential Output	NO
Protocol	RS232
Input Characteristics	SCHMITT TRIGGER
Number of Drivers/Receivers	2/2
Receiver Number of Bits	2
Duplex	Full
Receiver Hysteresis	300mV
Number of Drivers	2
Number of Transceivers	1
RoHS Status	ROHS3 Compliant

MAX3320TEAP+T Product Details

MAX3320TEAP+T Overview

With the enhanced 20-SSOP (0.209, 5.30mm Width) package, this driver IC is excellent for driving common LEDs.Tape & Reel (TR) package is used to mount this receiver.It has proved to be a valuable component for a variety of applications since it is a Transceiver can transceiver.The wide receiver can be mounted on any Surface Mount-type PCB or development board.In terms of power supply, this differential driver utilizes 3V~5.5V.This electronic part can have?up to 2/2 eligible receivers/drivers on the field at once.?IC receiver likes this one are designed for use in applications where operating temperatures are -40°C~85°C.An output voltage range of 3.3V is sufficient to run this line driver ic efficiently.For driving and receiving signals from data, this wide receiver has 20 terminations integrated.As a standard package, this transceiver comes with a 20-pin layout that follows the market standard.Since the base part number MAX3320 describes the product type, temperature, package, etc., you might get more options by searching with it.Wide receiver with enhanced power dissipation control, 20-pin.As a result of optical transceiver downsizing and high-density Surface Mount mounting technologies, its package size has been greatly reduced.It is typical for this receiver to have a resolution of 2 bits when it is specified.There is a voltage supply of 5.5V required in order for this transceiver module to be operated.There are 1 transceivers in total that this module isolated transceiver implements.The integrator circuit comes with embedded 2 drivers.There are 8 serial I/Os on board this IC, and it has a standard VGA interface.
