Name: MAX244EQH+TD
Brand: Maxim Integrated
SKU: MAX244EQH+TD
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-LCC (J-Lead)
Number of Pins	44
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	44
ECCN Code	EAR99
Type	Transceiver
Terminal Finish	Matte Tin (Sn)
Subcategory	Line Driver or Receivers
Technology	CMOS
Voltage - Supply	4.75V~5.25V
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Supply Voltage	5V
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	MAX244
Qualification Status	Not Qualified
Operating Supply Voltage	5V
Power Supplies	5V
Number of I/O	36
Nominal Supply Current	30mA
Propagation Delay	1.5 μs
Logic Function	Receiver, Transceiver
Data Rate	120Kbps
Differential Output	NO
Protocol	RS232
Number of Drivers/Receivers	8/10
Duplex	Full
Receiver Hysteresis	500mV
Number of Drivers	8
Number of Transceivers	1
Output Low Current-Max	0.0032A
Number of Receivers	10
High Level Input Current-Max	0.00005A
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MAX244EQH+TD Product Details

MAX244EQH+TD Overview

LED drivers benefit from this IC's enhanced 44-LCC (J-Lead) package.In this package, the receiver is mounted in the Tape & Reel (TR) format.It has proved to be a valuable component for a variety of applications since it is a Transceiver can transceiver.On any Surface Mount-type PCB or development board, you can install this wide receiver.A differential driver like this uses 4.75V~5.25V of power.It is possible to have up to 8/10 receivers/drivers in use simultaneously with this electronic part.In most applications, this ic receiver is used in environments where -40°C~85°C is the operating temperature.This line driver ic can operate efficiently with a supply voltage range of 5V.Wide receiver has 44 terminations built in for driving or receiving signals from data.Since the base part number MAX244 describes the product type, temperature, package, etc., you might get more options by searching with it.It is a 44-pin driver IC with enhanced power dissipation controls.A combination of optical transceiver downsizing and high-density Surface Mount mounting reduces the package size dramatically.There is a supply voltage of 5V on the input of this transceiver module, so it can be operated from that source.A rf transceiver module named Line Driver or Receivers belongs to this subcategory.An 8-pin power supply is provided by this driver IC, which allows it to operate from an 5V-pin power supply.There are 1 transceivers in total implemented by this IC.There are also 10 receivers in it as well.The integrator circuit is embedded with 8 drivers.It is an integrated circuit with 36 serial I/Os that are in line with industry standards.
