DG303ABK Overview
This is a relatively small item of digital switch that is included in the CDIP in order to save space on the board.The package is in the form of Tube.The basic configuration includes 14 terminations.The multiplexer's system is powered by 15V voltage.In this turn signal switch, there are 14 components that can be connected to each pin.At the end of a conductor, it uses THROUGH-HOLE as the point where the conductor ends.In this case, Dual, Single is employed as the supply type.In electronic terms, the digital switch ic is classified as Multiplexer or Switches.With a resistance of 50Ohm, it operates.This turn signal switch's circuit is based on a circuit with 2 channels.The maximum temperature for this signal switch is 85°C.In order to maintain a minimal operating temperature of the multiplexer, it should be set at -25°C.In compliance with the applicable device specification, the signal switches has a maximum supply voltage of 30V.The digital swith is specified to operate at the minimum supply voltage of 10V in compliance with the applicable device specification.In this digital switch, SPDT serves as the analog integrated circuit.
DG303ABK Features
Supplied in the CDIP package
Adopting a supply type of Dual, Single
SPDT as the analog IC
DG303ABK Applications
There are a lot of Maxim Integrated DG303ABK Signal Switches / Multiplexers / Decoders applications.
