LTST-C19HE1WT datasheet pdf and LED Indication - Discrete product details from Lite-On Inc. stock available on our website
SOT-23
LTST-C19HE1WT Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
12 Weeks
Mount
Surface Mount
Mounting Type
Surface Mount
Package / Case
0606 (1616 Metric)
Number of Pins
4
Packaging
Tape & Reel (TR)
Published
2014
Size / Dimension
1.60mm Lx1.60mm W
Part Status
Active
Moisture Sensitivity Level (MSL)
3 (168 Hours)
Max Operating Temperature
80°C
Min Operating Temperature
-20°C
Color
Red, Green, Blue (RGB)
Subcategory
Visible LEDs
Depth
1.6mm
Case Code (Metric)
1616
Case Code (Imperial)
0606
Number of Elements
3
Configuration
Common Anode
Voltage - Forward (Vf) (Typ)
2.1V Red 3.35V Green 3.35V Blue
Viewing Angle
130°
Optoelectronic Device Type
TRIPLE COLOR LED
Forward Current
20mA
Current - Test
20mA Red 20mA Green 20mA Blue
Lens Style
Rectangle with Flat Top
Lens Size
1.15mmx1.60mm
Luminous Intensity
180 mcd
Millicandela Rating
112.5mcd Red, 281mcd Green, 104mcd Blue
Lens Transparency
Diffused
Wavelength - Peak
632nm Red 520nm Green 468nm Blue
Lens Color
White
Reverse Voltage
5V
Wavelength - Dominant
624nm Red 525nm Green 470nm Blue
Height
350μm
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free
In-Stock:14929 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
LTST-C19HE1WT Product Details
The Lite-On LTST-C19HE1WT is a discrete LED indication component with an RGB diffused chip in an SMD 0805 package. This component is designed to provide a bright, uniform light output with a wide viewing angle. It is ideal for applications that require a high level of visibility and color differentiation.
Features of the Lite-On LTST-C19HE1WT include: - High luminous intensity of up to 20 mcd - Wide viewing angle of up to 120° - Low power consumption of up to 20 mA - RoHS compliant - Operating temperature range of -40°C to +85°C
Applications of the Lite-On LTST-C19HE1WT include: - Automotive lighting - Industrial lighting - Home appliances - Consumer electronics - Signage and displays - Medical equipment - Telecommunications equipment
