LTST-C155GEKT datasheet pdf and LED Indication - Discrete product details from Lite-On Inc. stock available on our website
SOT-23
LTST-C155GEKT Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
12 Weeks
Mount
Surface Mount
Mounting Type
Surface Mount
Package / Case
1210 (3225 Metric)
Number of Pins
4
Shape
RECTANGULAR
Manufacturer Package Identifier
BNS-OD-C131/A4
Packaging
Tape & Reel (TR)
Published
2000
Size / Dimension
3.20mm Lx2.70mm W
Part Status
Active
Moisture Sensitivity Level (MSL)
3 (168 Hours)
Number of Terminations
4
ECCN Code
EAR99
Terminal Finish
Pure Tin (Sn)
Max Operating Temperature
85°C
Min Operating Temperature
-55°C
Color
Green, Red
Additional Feature
IC COMPATIBLE
Subcategory
Visible LEDs
Packing Method
TAPE AND REEL 7"
Number of Functions
1
Terminal Pitch
3.5mm
Depth
3.2mm
Case Code (Metric)
3225
Case Code (Imperial)
1210
Number of Elements
2
Configuration
Independent
Power Dissipation
100mW
Voltage - Forward (Vf) (Typ)
2.1V Green 2V Red
Viewing Angle
130°
Optoelectronic Device Type
DUAL COLOR LED
Forward Current
20mA
Current - Test
10mA Green 10mA Red
Lens Style
Rectangle with Flat Top
Lens Size
2.06mmx2.70mm
Luminous Intensity
6 mcd
Millicandela Rating
7mcd Green, 6mcd Red
Illumination Color
Green, Red
Lens Transparency
Clear
Wavelength - Peak
565nm Green 630nm Red
Lens Color
Colorless
Reverse Voltage
5V
Wavelength - Dominant
569nm Green 621nm Red
Height
1.2mm
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free
In-Stock:24362 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
LTST-C155GEKT Product Details
Description: The Lite-On LTST-C155GEKT is a discrete LED indication device with a green/red clear chip in a SMD 0805 package. It is designed to provide a bright, reliable indication of status or presence in a variety of applications.
Features: - Bright, reliable indication of status or presence - Green/red clear chip in a SMD 0805 package - Low power consumption - RoHS compliant
Applications: The Lite-On LTST-C155GEKT is suitable for a variety of applications, including automotive, consumer electronics, industrial, and medical. It can be used for status indication, warning signals, and other visual indicators.
