LTC6946IUFD-1 Overview
As a clock IC, it is packaged by the Tube method. In the 28-WFQFN Exposed Pad package, there is an embedded clock generator. The input of this clock generator is designed to be Clock. A total of 1 circuits are implemented to access the full performance of the electrical part. There is a maximum frequency of 3.74GHz Max with this clock-based frequency generator. This component can be conveniently installed on the panel thanks to the Surface Mount. There are 3.15V~5.25V available for use with this clock PLL. Statistics suggest that the ambient temperature be set at -40°C~105°C, which is what is estimated by the test. This electronic component can be classified into Clock/Frequency Synthesizer (RF/IF), Integer N. Clock PLL is equipped with 28 pin count. Related electrical parts can be found for the base part number LTC6946.
LTC6946IUFD-1 Features
Available in the 28-WFQFN Exposed Pad
LTC6946IUFD-1 Applications
There are a lot of Linear Technology/Analog Devices LTC6946IUFD-1 Clock Generators applications.
- DVD add-on cards for multimedia PCs
- Media broadcast servers
- Tracking filters
- VSAT (Small Ground Satellite Station)
- Communication infrastructure
- Modems
- Mobile telephones
- 1 Gigabit Ethernet
- Wide area power system
- Set-top boxes
