Name: LT3070IUFD
Brand: Linear Technology/Analog Devices
SKU: LT3070IUFD
Availability: InStock

new-10%

LT3070IUFD

Manufacturer part number:LT3070IUFD

Manufacturer:Linear Technology/Analog Devices

Description:Enable, Power Good, Soft Start Programmable 0.5mm PMIC 28 28-WFQFN Exposed Pad

Case Package:SOT-23

Datasheet:LT3070IUFD Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	28-WFQFN Exposed Pad
Surface Mount	YES
Operating Temperature	-40°C~125°C
Packaging	Tube
Published	2006
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	235
Number of Functions	1
Terminal Pitch	0.5mm
Reach Compliance Code	not_compliant
Time@Peak Reflow Temperature-Max (s)	20
Pin Count	28
JESD-30 Code	R-PQCC-N28
Current - Supply (Max)	2.3mA
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	3V
Output Type	Programmable
Output Configuration	Positive
Current - Output	5A
Control Features	Enable, Power Good, Soft Start
Voltage - Output (Min/Fixed)	0.8V
Number of Regulators	1
Protection Features	Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)	1.8mA
Voltage Dropout (Max)	0.15V @ 5A
PSRR	66dB (120Hz)
Dropout Voltage1-Nom	0.085V
Output Voltage1-Min	0.8V
Voltage - Output (Max)	1.8V
Adjustability	ADJUSTABLE
Load Regulation-Max(%)	2.2%
Length	5mm
Height Seated (Max)	0.8mm
Width	4mm
RoHS Status	Non-RoHS Compliant

LT3070IUFD Product Details

LT3070IUFD Overview

Tube cases are used for delivery. The Liner regulator IC is packaged in 28-WFQFN Exposed Pad case. On the Linear IC itself, there are 28 terminations. Programmable is the output type of the Voltage Regulator IC. As part of this electrical component, 1 regulators are implemented. Variations are made to the Surface Mount operating temperature range by the Voltage Regulator IC. Default settings are set to -40°C~125°C degrees. There is a Positive configured as the output function for this IC regulator. There is a current output of 5A from this regulator IC. On this chip, there are a total of 28 pins in total. There are 1 outputs total on this voltage regulator IC in order to ensure that prompt and sufficient performance is achieved.
