LT1764AEFE-3.3#PBF Overview
A Tube case is used to deliver the Voltage Regulated IC. A 16-TSSOP (0.173, 4.40mm Width) Exposed Pad case is used for packaging. As you can see, the IC chip has 16 terminations. Regulator IC chip's output type is Fixed. The electronic part implements 1 regulators in total. In this Regulator IC chip, the operating temperature of Surface Mount varies. -40°C~125°C degrees is the operating temperature of the Voltage Regulator IC. There is one output function configured for this voltage regulator IC, and that is Positive. As far as its current output is concerned, it stands at 3A. There are 16 pins in total in this voltage regulator IC. It has 1 outputs to ensure that the performance of this regulator is prompt and sufficient. The dropout voltage of the regulator IC is 10 volts. 16 pins are on the chip. For your information, this regulator's basic part number is LT1764. With a supply current of 1mA, the regulator IC operates.
LT1764AEFE-3.3#PBF Features
340mV dropout voltage
LT1764AEFE-3.3#PBF Applications
There are a lot of Linear Technology/Analog Devices
LT1764AEFE-3.3#PBF Linear Voltage Regulators applications.
- Communication device
- Personal communication device
- Portable telephone
- Electronic notebook
- Camera
- Video equipment
- CPU power supply
- Switching regulator
- Multiple-power supply system
- Digital audio player
