Res Thick Film 0805 100K Ohm 1% 0.125W(1/8W) ±100ppm/C Molded SMD Automotive Punched Paper T/R
SOT-23
RK73H2ATTD1003F Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
8 Weeks
Package / Case
0805 (2012 Metric)
Number of Pins
2
Supplier Device Package
0805
Operating Temperature
-55°C~155°C
Packaging
Tape & Reel (TR)
Published
2007
Series
RK73H
Size / Dimension
0.079Lx0.049W 2.00mmx1.25mm
Tolerance
±1%
Feature
Automotive AEC-Q200, Moisture Resistant
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Number of Terminations
2
Termination
SMD/SMT
Temperature Coefficient
±100ppm/°C
Resistance
100kOhms
Max Operating Temperature
155°C
Min Operating Temperature
-55°C
Composition
Thick Film
Power (Watts)
0.25W 1/4W
Voltage - Rated
150V
Power Rating
125mW
Voltage - Rated DC
150V
Depth
1.25mm
Military Standard
Not
Case Code (Metric)
2012
Case Code (Imperial)
0805
Height
500μm
Height Seated (Max)
0.024 0.60mm
Length
2mm
Width
1.25mm
REACH SVHC
Unknown
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free
Ratings
AEC-Q200
In-Stock:63700 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.050947
$0.050947
500
$0.037461
$18.7305
1000
$0.031218
$31.218
2000
$0.028640
$57.28
5000
$0.026766
$133.83
10000
$0.024899
$248.99
15000
$0.024080
$361.2
50000
$0.023678
$1183.9
RK73H2ATTD1003F Product Details
The KOA Speer Chip Resistor - Surface Mount RK73H2ATTD1003F is a high-performance, automotive-grade resistor designed for use in a variety of applications. This resistor features a 0805 package size, a resistance value of 100K Ohms, and a tolerance of 1%. It is constructed with a thick film technology and has a power rating of 0.125W (1/8W). The temperature coefficient is ±100ppm/C, and the resistor is molded with a SMD design. It is also packaged in punched paper tape and reel for easy installation. This resistor is ideal for automotive, industrial, and consumer applications that require a reliable, high-performance resistor.
