PHE426KD7150JR06L2

  • PHE426KD7150JR06L2 - PHE426 1.5μF Film Capacitor ±5% Radial PC Pins 400V-DC 220V-AC Polypropylene (PP), Metallized
  • PHE426KD7150JR06L2 - PHE426 1.5μF Film Capacitor ±5% Radial PC Pins 400V-DC 220V-AC Polypropylene (PP), Metallized

PHE426KD7150JR06L2

PHE426KD7150JR06L2

KEMET

PHE426 1.5μF Film Capacitor ±5% Radial PC Pins 400V-DC 220V-AC Polypropylene (PP), Metallized

SOT-23

PHE426KD7150JR06L2 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 21 Weeks
Mounting Type Through Hole
Package / Case Radial
Surface MountNO
Terminal Shape WIRE
Number of Pins 2
Dielectric MaterialPolypropylene (PP), Metallized
Operating Temperature-55°C~105°C
PackagingBulk
Series PHE426
Size / Dimension 1.024Lx0.531W 26.00mmx13.50mm
Tolerance ±5%
JESD-609 Code e3
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination PC Pins
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications DC Link, DC Filtering; High Frequency, Switching; High Pulse, DV/DT
Capacitance 1.5μF
Voltage - Rated DC 400V
Packing Method Tray
Voltage - Rated AC 220V
Lead Pitch 22.5mm
Capacitor Type FILM CAPACITOR
Dielectric PP
Lead Spacing0.886 22.50mm
Lead Diameter 800 μm
Lead/Base Style Straight
Height 23mm
Height Seated (Max) 0.906 23.00mm
Width 13.5mm
RoHS StatusRoHS Compliant
In-Stock:6379 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$2.297281$2.297281
10$2.167246$21.67246
100$2.044572$204.4572
500$1.928841$964.4205
1000$1.819661$1819.661

PHE426KD7150JR06L2 Product Details

PHE426KD7150JR06L2 Overview


A 0.886 22.50mm lead spacing is used in this electrical device.It is capable of operating at -55°C~105°C degrees Celsius.

PHE426KD7150JR06L2 Features



PHE426KD7150JR06L2 Applications


There are a lot of KEMET PHE426KD7150JR06L2 applications of film capacitors.

  • Lighting
  • Battery management system
  • Mobile communications
  • RF Modules
  • Bypassing
  • Global positioning systems
  • Snubbering
  • Audio/video equipment
  • IGBT
  • Switch mode power supplies
