Name: 500X14W103MV4T
Brand: Johanson Dielectrics Inc.
SKU: 500X14W103MV4T
Price: 0.36000 USD
Availability: InStock

new-10%

500X14W103MV4T

Manufacturer part number:500X14W103MV4T

Manufacturer:Johanson Dielectrics Inc.

Description:500X14W103MV4T datasheet pdf and Ceramic Capacitors product details from Johanson Dielectrics Inc. stock available on our website

Case Package:SOT-23

Datasheet:500X14W103MV4T Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount, MLCC
Package / Case	0603 (1608 Metric)
Terminal Shape	WRAPAROUND
Number of Pins	4
Dielectric Material	CERAMIC
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Published	2006
Series	X2Y®
Size / Dimension	0.064Lx0.035W 1.63mmx0.89mm
Tolerance	±20%
JESD-609 Code	e3
Feature	Low ESL (X2Y)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	SMD/SMT
ECCN Code	EAR99
Temperature Coefficient	X7R
Terminal Finish	Matte Tin (Sn) - with Nickel (Ni) barrier
Applications	Bypass, Decoupling
Capacitance	10000pF
Voltage - Rated DC	50V
Packing Method	TR, PUNCHED, 7 INCH
Depth	889μm
Case Code (Metric)	1608
Case Code (Imperial)	0603
Capacitor Type	CERAMIC CAPACITOR
Temperature Characteristics Code	X7R
Multilayer	Yes
Height	660μm
Thickness (Max)	0.026 0.66mm
Thickness	660.4μm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant

500X14W103MV4T Product Details

500X14W103MV4T Overview

Using this device, the program has a size/dimension of 0.064Lx0.035W 1.63mmx0.89mm.Its coefficient is X7R and determines the change in resistance per degree of temperature for a substance.With a voltage of 50V, it can operate.
