MOC3021XSM datasheet pdf and Optoisolators - Triac, SCR Output product details from Isocom Components 2004 LTD stock available on our website
SOT-23
MOC3021XSM Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
2 Weeks
Mounting Type
Surface Mount
Package / Case
6-SMD, Gull Wing
Number of Pins
6
Operating Temperature
-40°C~100°C
Packaging
Tube
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Max Operating Temperature
100°C
Min Operating Temperature
-40°C
Approval Agency
UR, VDE
Voltage - Isolation
5300Vrms
Output Voltage
400V
Output Type
Triac
Number of Channels
1
Voltage - Forward (Vf) (Typ)
1.2V
Current - DC Forward (If) (Max)
50mA
Voltage - Off State
400V
Input Current
10mA
Current - Hold (Ih)
100μA
Zero Crossing Circuit
No
Current - LED Trigger (Ift) (Max)
15mA
Static dV/dt (Min)
10V/μs (Typ)
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
In-Stock:7805 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.90000
$0.9
10
$0.69600
$6.96
25
$0.57680
$14.42
100
$0.49730
$49.73
250
$0.43760
$109.4
500
$0.37792
$188.96
MOC3021XSM Product Details
The MOC3021XSM optoisolator by Isocom Components 2004 LTD is a surface-mountable, 6-pin SMDIP device designed to provide high-level signal and power isolation. The device features a TRIAC output and has a current threshold (IT) of 10mA. This optoisolator offers 1500Vrms of isolation, protecting against power and signal integrity issues. With its low power consumption and reliable isolation, this optoisolator is an ideal solution for safety-critical, low to moderate power applications. The MOC3021XSM is easy to install and use, and provides reliable performance in a variety of industrial and consumer applications.
