Name: IPI80N06S208AKSA1
Brand: Infineon Technologies
SKU: IPI80N06S208AKSA1
Availability: InStock

new-10%

IPI80N06S208AKSA1

Manufacturer part number:IPI80N06S208AKSA1

Manufacturer:Infineon Technologies

Description:MOSFET OptiMOS PWR TRANST 55V 80A

Case Package:SOT-23

Datasheet:IPI80N06S208AKSA1 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	TO-262-3 Long Leads, I2Pak, TO-262AA
Surface Mount	NO
Transistor Element Material	SILICON
Operating Temperature	-55°C~175°C TJ
Packaging	Tube
Published	2006
Series	OptiMOS™
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Technology	MOSFET (Metal Oxide)
Terminal Position	SINGLE
JESD-30 Code	R-PSIP-T3
Number of Elements	1
Configuration	SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max	215W Tc
Operating Mode	ENHANCEMENT MODE
FET Type	N-Channel
Rds On (Max) @ Id, Vgs	8m Ω @ 58A, 10V
Vgs(th) (Max) @ Id	4V @ 150μA
Input Capacitance (Ciss) (Max) @ Vds	2860pF @ 25V
Current - Continuous Drain (Id) @ 25°C	80A Tc
Gate Charge (Qg) (Max) @ Vgs	96nC @ 10V
Drain to Source Voltage (Vdss)	55V
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±20V
Drain Current-Max (Abs) (ID)	80A
Drain-source On Resistance-Max	0.008Ohm
Pulsed Drain Current-Max (IDM)	320A
DS Breakdown Voltage-Min	55V
Avalanche Energy Rating (Eas)	450 mJ
RoHS Status	ROHS3 Compliant

About IPI80N06S208AKSA1

The IPI80N06S208AKSA1 from Infineon Technologies is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET OptiMOS PWR TRANST 55V 80A.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the IPI80N06S208AKSA1, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
